| Prod Model: |
HBGQ19B-10/S |
| LED Color: |
Red, Green, Yellow, Orange, White, Blue |
| Diameter: |
19mm |
| Voltage: |
2V, 6V, 12V, 24V, 36V, 110V, 220V |
| Termianl: |
Pin Terminal |
| IP: |
IP65, Ik09 |
| Crust Material: |
Stainless Steel |
| Switch Rating: |
5A/250V AC |
| The Front Shape: |
Flat Round |
| Operation Pressure: |
4n |
| Operation Stroke: |
About 2.5 mm |
| Type: |
Composite |
| Usage: |
Reset Button |
| Kind: |
Single-pole on-off Switch |
| Contact Type: |
Za |
| Brand: |
Hban |
| Certification: |
TUV RoHS |
Product Description
19mm momentary metal waterproof stainless steel screw ternimal push button switch
Mounting hole size:19mm
Switch Rating:2A /36V AC
| Item No. | HBGQ19B-10/N | HBGQ19B-10/S |
| Specification | 1NO Momentary | 1NO Momentary |
| Item No. | HBGQ19B-01/N | HBGQ19B-01/S |
| Specification | 1NC Momentary | 1NC Momentary |
| Front Head Shape |
| Domed |
| Terminal Type |
| Screw Terminal |
| Switch Type |
| X(Two terminal breakpoints slow moving contact) |
| Switch Specification | 2A/36VDC |
| Contact Resistance | ≤50m Ω |
| Insulation Resistance | ≥1000MΩ |
| Dielectric Strength | 2000V AC |
| Operating Temperature | -20degree~+55degree |
| Machanical Life | >1,000,000 times |
| Electrical Life | >200,000 times |
| Panel Thickness | 1~10mm |
| Torque | 5~14Nm |
| Operating Pressure | About 4N |
| Operating Stroke | About 1.8mm |
| Protection Degree | IP65,IK09 |
| Material | Contact | Sliver Alloy |
| Button | Mirror Surface |
| Case | Nickel-plated Brass | Stainless Steel |
| Base | PBT |
| RoHS | Can be made to order |
Packing Details:
We pack 40 pieces diameter 19 mm push button switch into 1 foam box to protect them .We supply 40 pieces rubber rings and 1 piece guarantee card with these switches.Then we packed this foam box into a plastic bag,it will packed into a small box with 3 layers corrugated .Finally ,we packed 20 boxes / 25 boxes into a 5 layers corrugated export carton.
Packing Details:
We pack 40 pieces diameter 19 mm push button switch into 1 foam box to protect them .We supply 40 pieces rubber rings and 1 piece guarantee card with these switches.Then we packed this foam box into a plastic bag,it will packed into a small box with 3 layers corrugated .Finally ,we packed 20 boxes / 25 boxes into a 5 layers corrugated export carton.
