1A 2A 3A 4A 5A 6A Circuit Breaker C45 MCB
| Price: |
US $ 1.85-1.96/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
C45 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rated Current: |
1A-63A |
| Rated Voltage: |
230/440V |
| Cover: |
Fireproof |
| Product Warrantly: |
3 Years |
| Product Function: |
Short Circuit and Ove |
| Service: |
OEM Oed |
| Place Of Origin: |
Zhejiang, China (Mainl |
| Breaking Capacity: |
Low Voltage Circuit Breakers |
| Operation: |
Manual Type |
| Speed: |
Normal Type Circuit Breaker |
| Arc-extinguishing Medium: |
Air |
| Installation: |
Fixed |
| Structure: |
MCB |
| Poles Number: |
3 |
| Certification: |
CCC |
Product Description
The product of L7 belong to the advanced level of the nineties in the world instead of the older generation of L7. They have protective function as shortage as overload, and are used in lighting distribution system in industry, commerce and dwelling, and protect fractional electric motors. And they also have many merits of high protective grade (up to IP20), high break capacity, reliable sensitive action, convenient, multiple assembling. Long life etc, they are mainly adapted to the circuit of AC50Hz, 230V in single pole, 400V in double, three, four poles for protecting overload and short circuit. Meanwhile, they are also used in turning on or off the electric apparatus and lighting circuit under the normal condition.
Specification
4
| Feature | 1) .Circuit breaker Pole No.: 1P,2P,3P,4P,1P+N,3P+N |
| 2) .Rated Voltage:230/400V |
| 3) .Rated Current(A): 1,2,3,4,5,6,10,16,20,25,32,40,50,63 |
| 4). Tripping curve: B, C, D |
| 5) .Rated frequency: 50/60HZ |
| 6) .Warranty period: 5 years warranty |
| 7).Installation: On symmetrical DIN rail 35mm /Panel Mounting |
| 8).Electro-mechanical life: 10000 |
| Packing | 12pcs/inner box, 120pcs/carton |
| Samples | 1).Hand sample time:within 7-15 days |
| 2).sample charge:according to product details |
| 3).sample refund:Negotiable |
| 4).send sample:Via TNT, UPS,FedEx,DHL Express |
| Payment | T/T,Western Union,L/C |
| Delivery Time | 7-30days according to quantity |
| Shipping Port | Ningbo/Shanghai Port |
Current Interrupter
1. Standard:IEC60898/GB10963
2. Beaking capacity:3KA,4.5KA,6KA
3: Certificate:ISO9001/CE/CB
Yueqing Heng Nuo Imp. & Exp. Co., Ltd. is the export department for TENGEN GROUP Co., Ltd, it is one leading manufacturer and exporter in the fields of electrical apparatus, wiring accessories, hardware, fire alarm system, tools and so on, our company located in Liushi town of Wenzhou city where is the largest production centre in China for electrical products.
From 1983 to now, our company has cooperated with more than 80 factories, and produces over 20 kinds, thousands of models of high quality electric products yearly. Mainly including:
1. Electrical apparatus: Circuit breaker, AC contactor, Relay, fuse, timer, counter, distribution box, meter socket, current transformer, meter, pushbutton switch, LED pilot lamp, limit switch, pedal switch, float switch, industrial plug & socket, Stabilizer and so on.
2. Wiring accessories: Cable tie, cable clip, cable puller, cable marker, cable lugs, cable glands, terminal blocks, wiring ducts, insulated terminals, MCB insulated busbar, dinrail and so on.
3. Hardware: Flexible conduit & connector, EMT fittings, Metal switch boxes and so on.
4. Tools: Hand crimping tools, cable cutter, hydraulic crimping tool, tester, screwdriver and so on
5. Fire alarm and warning system: Fire alarm bell, electric bell, smoke detector, motor siren, buzzer, warning light and so on
Internationalization standard quality guarantee system:
The product quality of Tengen Group has been strictly controlled in each working procedure,
Many kinds of internationalization standard quality guaranteed system can be highly effective
Under company's strict monitoring. Fellowtrader commended, customer's approval can sufficiently
Make sure of our product quality.
"Tengen" was evaluated as " Chinese famous trademark", Tengen Group has obtained American
FMRC Corporation ISO9001 quality system authentication, ISO14001 environment management
System authentication, CCC authentication, European Union CE safe Authentication, American UL
Authentication and Dutch KEMA authentication and so on, at the same time, it has had the first
Side laboratory -- low voltage electric appliance test center which is the first connected with
International in China.
We promise to offer you superior products, favorable price, and timely delivery. If you are interested in cooperating with us, please feel free to contact with us in your earliest convenience time.
