| Prod Model: |
HDX plus 1kva/HDX plus 1.2kva/HDX plus 2kva |
| Product Name: |
1kVA 1.2kVA 2kVA Modified Sine Wave Homeage Invert |
| Application: |
Home Appliance |
| Output Waveform: |
Modified Sine Waveform |
| Protection: |
Discharge, Over Charge, Over Load, Over Temperatur |
| AC Input/Output Voltage: |
220/230/240V |
| DC Voltage: |
12/24VDC |
| Display: |
LCD+LED |
| Warranty: |
2 Years |
| Weight: |
1.5-2.5kg |
| Dimension: |
373mm(D)*121mm(W)*305mm(W) |
Product Description
High frequency 1kva 1.2kva 2kva modified sine wave homeage inverter in Pakistan with charger
Key features:♦Automatic line-to-battery switchover.
♦Configurable Input voltage ranges via LCD setting.
♦High efficient DC-to-AC conversion, minimizing energy loss.
♦Rack design & wall-mounted design for flexible installation.
♦Built-in enhanced charger.
♦Intelligent 3-stage charger control for efficient charging and
preventing overcharge.
♦Auto restart while AC recovery.
♦User-friendly LCD+LED indications.
♦Multiple protection: low battery alarm, low battery shutdown,
over charger protection, overload protection,over temperature
protection, short circuit protection.
Product Introduction
Application:
HDX is a DC-to-AC inverter without auto line-to-battery transfer and integrated charging system, serving as an extended run UPS,a standalone power source or an automotive inverter.
HDX supplies power from AC power and DC source. When AC cable is connected to a wall socket, utility power goeds to connected equipment(s) and/or charges the battery set via charging system.
In battery mode, HDX automatically converts battery energy into AC power for backing up the connected devices.
Product Parameters| Model Parameters | HDX Plus1K-12 | HDX Plus1.2K-12 | HDX Plus2K-24 |
| *1 Capacity | VA/W | 1000VA/700W | 1200VA/900W | 2000VA/1500W |
| Battery & Charger | VDC | 12VDC | 24VDC |
AC Input | Nominal input Voltage | 220/230/240VAC |
| Selectable Voltage Range | 170-280VAC (Narrow Range);90-280VAC (Wide Range) |
| AC Ouput | Output Voltage Waveform | Modified sine wave |
| Voltage | 230VAC |
| Voltage Regulation (Batt.Mode) | 10% / -18% |
| Frequency | 50/60Hz(Adjustable); |
| Frequency Regulation (Bat. Mode) | ±1HZ |
| Display Indicator | AC Mode | Display output power, output voltage |
| Battery Mode | | The mark will flicker every 1second. |
|
| Battery Charging Mode | Display the Battery capacity |
| Fault | Display fault |
| Efficiency | AC to AC | >95% |
| DC to AC | >80% |
| Battery & Charger | Charger Current | 20Amp | 15Amp |
| Overcharge Protection | 16V | 32V |
| Transfer Time | Typical | 15ms Typical, 40ms Max. |
| Solar Battery Charger | Max. Input Power | 450W | 900W |
| Charging Current | 40Amp |
| Nominal Batery Voltage | 12V | 24V |
| Optimal Work Voltage Range | 15V~18V | 30V~36V |
| Max.PV Input Voltage | 55V |
| Protection | Full Protection | Discharge, overcharge, overload, over temperature protection. |
General
Specifications | Operating Temperature
Range | 0- 50°C, 5%-90 % relative humidity (non-condensing) |
| Storage Environment | -15°C to 55°C, 5% to 95% humidity (non-condensing) |
| Noise Level | Less than 50dB |
| Dimension(L*W*H) | 373*121*305mm |
| Net Weight(kg) | 2.18kg | 2.49kg | 2.37kg |
3.About ZLPOWER:
ZLPOWER is the inverter & UPS fatory since 2006.
We mainly produce below FOUR types of inverters for your choice:
1. IG series is high frequency modified sine wave home inverter, from 500va to 2000va, 12v/24vdc to 220/230vac, built in 10amp AC charger, mainly used for home appliances and office equipments such as TV, fan, light, computers and so on.
2. LW series is low frequency pure sine wave powerstar inverter, LCD digital display, from 1000w to 6000w, 12v/24v/48vdc, 110/120vac or 220/230/240vac, built in 35amp or 70amp AC charger, mainly used for home (air conditioner, freezer, printer), office, industry, big equipments, solar power systems and so on.
3. PST HIGH FREQUENCY pure sine wave Inverter WITHOUT CHARGER 600W-3000W is mainly used for solar power station; home solar power systems, mobile solar power system and DC wind solar generating systems.
4. PSC LCD digital display high frequency pure sine wave inverter 3KVA-6KVA, with built in AC charger, mainly used for solar, wind or hybrid power systems.
4.FAQ:
Q1. What's the payment term?
A. We accept TT,30% deposit and 70% balance before shipment.
Q2. How's the delivery time?
A. usually it will take about 3-5 days for sample and 10-15 days for bulk production
Q 3. What kind of material of transformer?
A. 100% copper which has a long sevice life and higher efficiency.
Q4. Would you accept to use our logo?
A. We would provide free OEM order depends on your quantity.
Q5. We want to know month capacity.
A. It depends on different model. Total capacity is upto 10000 pieces.
Q6. Where is your market?
A. Our products are popular all over the world as their cost-effictive perfermance. We hope you can join us and make mutual benefit from our long-term and co-win cooperation.
Q7. Does the inverter connect with utility?
A.Yes.it is solar and utility complementary inverter. it combine invert, charge and AC auto-transfer switch into one complete case, it also can charge the battery by utility and generator.
