| Prod Model: |
SNU-15 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| MOQ: |
1 Unit |
| Provide: |
OEM/ODM Service |
| Phase: |
Single Phase |
| Type: |
On-line |
| Protection: |
Overvoltage |
| Application: |
Power System |
| Brand: |
Snat |
Product Description
1kVA 2kVA 3kVA manufacturer of online UPS for power system
Product introduction SNT high frequency online UPS, is designed to effectively solve the modern IT equipment and network communication application environments etc. high quality electricity made by SNAT company. With advanced modern IT equipment to achieve good matching of a new generation of intelligent UPS. To provide safe and reliable power protection for the following places:- the key server and network transmission equipment
- telecommunications equipment, including VOLP
- the bank and security system
- the medical system
- manufacturing and control system
- the laboratory equipment, precision instruments and meters, etc
Detailed parameters
Function characteristics:
-On-line double transform structure design, providing continuous clean electricity, protect the key electric equipment from blackout of power grid,electricity unstable, frequency drift, harmonic interference etc. effects.
-Humanized design, LED status display, easy to management and operation
-High efficiency, high input/output power factor, comprehensive matched modern IT load equipment, energy conservation and environmental protection
-Pure sine wave output
-Wide range of input frequency (40-70 hz), adaptive output frequency 50/60 hz, meet all kinds of generators to access
-Zero switching time
-Enter zerowire firewire reverse detection function
-Automatic restart function
-Automatic detection function, under-voltage and bypass and emergency shutdown etc. protection function
-Abundant output power distribution and communication monitoring to choose the parts, meet the installation of IT administrators and management requirements
-To adapt to different countries power grid environment, strong load capacity, high efficiency
-High reliability, stable quality, good compatibility, strong anti-jamming capabilityTECHNOLOGY PARAMETER| SNT high-frequency series on-line UPS |
| Model | 1K | 1KL | 2K | 2KL | 3K | 3KL |
| Rated capacity(W) | 1KVA/0.8 | 2KVA/1.6 | 3KVA/2.4 |
| Input | Rated voltage | 145-285VAC |
| Frequency range | 40-60 hz (software adjustable) |
| Power factor | >0.98 |
| Output | voltage | 220VAC±2% |
| frequency | 50Hz±0.1% (battery mode) |
| waveform | Pure sine wave |
| Distortion (THD) | Linear load≤3%, nonlinear load≤6% |
| Overload capacity | Mains mode, the load is 105% - 150% for 30 seconds, load > 150% when 300 milliseconds later, to bypass mode and report to the police |
| Batteries work mode, load is 105% - 150% for 30 seconds, load > 150% when 300 milliseconds close output and alarm |
| peak factor | 3:1 |
| Battery | type | Valve control type free maintenance battery |
| Nominal voltage | 24VDC | 36VDC | 48VDC | 72VDC | 72VDC | 96VDC |
| Standby time(full/half load) | mintues | 5/15 standard type/long-acting type depends on external battery capacity |
| Conversion time | 0 ms (electricity and battery) |
| Protective capability | Overload, short circuit, overvoltage, undervoltage, overheating, TVSS |
| Display | LED | UPS operation status indicator, battery capacity, load |
| Noise | 1meter distance | <45dB | <50dB |
| Communication interface | RS232USB | standard RS - 232 |
| Intelligent shot | Optional collocation: SNMP card, AS400 card |
| operating environment | environment temperature | 0-40ºC |
| Relative humidity | 0-95% no condensation |
FAQ:
Q1: MOQA: MOQ from our company is required 1 unitQ2: Are you manufacturer or trading company?A: We are professional manufacturer since 2004Q3:I need this product and wanna a system for family/industrial/commerical using, can you help me? A: Yes, we have a professional technology team average 10 years' experience, they can design solar power system in accordance with customers' special requirements.Q4: How long is your delivery timeA: Within 15 daysQ5:How about your after-sales service?A:Our quality warranty for 2 years; any parts will be shipped for free during warranty period.Q6: Why choose us?A1)Prompt delivery and good after-sale services.
A2)We have our own factory,the selling prices is competitive.
A3)All of our products are certified with CE, RoHS, ISO9001:2008.
A4)100% new materials for production and superior quality.
A5)Professional R&D technology team average 10 years experience.
