2.0mm SC-SC Singlemode Fiber Optic Patch Cords

Prod Model:	653
Color:	Yellow
Application:	Communication
Type:	Multi-mode Fiber
Connection Structure:	SC
Certification:	CCC
Brand:	Puno
Sheath Material:	LSZH

Product Description

2.0mm SC-SC Singlemode Fiber Optic Patch Cords

Description:

The fiber optic patch cords are mainly used on patch panel or for the connection between outlets and terminal equipments. The quality of connectors and fibers are mainly determined by the insertion loss and
return loss. We supply simplex LC-FC multi mode fiber optic patch cords, these patch cords are with 50/125 and 62.5/125 multi mode fiber, and connector types in PC, UPC polish are available. It's fully complied with IEC and Telcordia GR-326 standards; they are good prices, fast delivery and good looking and packing.

Features:

√ Combines two fibers for bi-directional data transmission into a single 3 mm jacket LC or SC connectors;
√ Offered in a variety of selection of cable types including Single Mode, Mult-Mode 50/125, Multimode 62.5/125, Multi-Mode 50/125 laser optimized;
√ Offered in both riser or plenum rated cables.

Benefits:

√ Reduces Rack space by 50% freeing up for more cable connections or better organization;
√ Cost effective solution;
√ Unique labeling system (serial number, part number, and product name) on both ends for ease of installation.



Specifications:


Fiber Type	SM		MM
Polishing	UPC	APC	PC
Insertion loss	< 0.3dB	< 0.5dB	< 0.3dB
Return loss	≥ 50dB	≥ 60dB	≥ 25dB
Durability	> 1000 Matings		> 1000 Matings
Core Diameter	9/125μm		50/125μm or 62.5/125μm
Operating Temperature	-40ºC to 80ºC

Environmental Compliance:

√ Telecorida GR-326-CORE;
√ TIA/EIA-568B-B.3 Fiber Optic Cabling Components Standard;
√ IEE802.3z Standards for Fiber Optic Cabling;
√ RoHS Certified for European market requirements.
