2 Pin 3 Pin Junction Box Wago Quick Pressure Wire Terminal

Name: 2 Pin 3 Pin Junction Box Wago Quick Pressure Wire Terminal
Brand: all-electronics-online.com
SKU: 790670765
Availability: InStock
Rating: 4.5 (102 reviews)

Price:	US $ 0.0321/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	Quick Connect Terminal
Type:	Socket Terminals
Application:	Transmission of Electrical Signals
Material:	Plastic
Brand:	Jwl

Product Description

1.Features:
Safety-Can avoid wire loosing, adhesive aging, wire fire risk etc.

Convenience - There is a test hole. No need to remove the adhesive tape for Voltage testing.
Reliability- Every contact is independent, firm combination of different diameter security short circuit.
Utility- The wire can be directly inserted after stripping , it is reusable

2.Technical parameters:

Wire cross section(mm2):	0.08-2.5(Single laid wire ) 0.08-4.0(Stranded conductor )	Insulation material:	PA66
Rated voltage/Current (V/A):	400/24	Anti-fire Grade:	V-0 or V-2
Rated impulse voltage(KV):	4	Contact material:	Copper alloy
Strip length(mm):	9-11	Contact points:	Tin coating

Specification:

Total number of connection points:5
1.Total number of potentials:1
2.Color:gray
3.Rated voltage EN:400V
4.Rated surge voltage:4kV
5.Nominal current:32A

Connection technology:CAGE CLAMP

Connection type:solid+fine-standed
Cross section from:0.08 mm² (28AWG)
Cross section up to:2.5 mm² (14AWG)

Compact splicing connector;3-conductor terminal block;with operating levers;max. contunuous service temperature 85 °C

Our company is a key electrical accessories manufacturer of terminal blocks and other cable accessories in China.

Our company is located in Yueqing, Wenzhou City, Zhejiang Province. It is a manufacturing and export company, specialized in producing components for kinds of lights, automobile and so on. They have gone through many authentications such as CQC, CE, RoHS. The main products are terminal blocks and wires, cable ties, cable clips, cable glands and copper inserts. They have entered the mafket of most parts in the world including Europe, the Middle East and Latin America. They are of good quality and sell well in many countries.

Our company manufactures products strictly according to IEC and national GB standards, and we have established a complete and improved quality management system according with ISO9002 standard system, We guarantee the products with competitive price, high quality and timely delivery. Besides, we can supply a complete set of after-sales service to our customers and help term expand their local market share.

We welcome you to contact us for more information and we are looking forward to chances of creating a long and mutually beneficial partnership with you. We do hope to cooperate very very well and develop rapidly with our joint efforts for mutual benefits.
