2000W Low Frequency Pure Sine Wave Inverter with Cooper Transformer

Name: 2000W Low Frequency Pure Sine Wave Inverter with Cooper Transformer
Brand: all-electronics-online.com
SKU: 765218205
Availability: InStock
Rating: 4.4 (101 reviews)

Price:	US $ 215.2-241/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	10/Piece
Pay Type:	L/C,T/T,D/P,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	LW series inverter
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Phase&Wave Form:	Single Phase & Pure Sine Wave
Display:	LCD and LED
Can Connect Generator:	Yes
Charge Current Adjustable:	Yes
Frequency:	50Hz and 60Hz Adjustable
AC Voltage:	120VAC/230VAC or 220/230/240VAC
Power Factor:	1.0
Color:	White
Warranty:	2 Years
Delivery Time:	1000PCS Within 15days

Product Description

2000W Low Frequency Pure Sine Wave Inverter with Cooper Transformer

Application
Model:LWS 500W-8000W Pure Sine Wave, low frequency Inverter
It is widely applied in wind generator, solar power system, house, vehicle, ship, navigation and places where lack of city power, mobile electricity work and telecommunications device, launch station, emergency EPS.

New Function
1. AC bypass output automatically , NO need to power on the inverter
2. Can charge the batttery even if the inverter is off (as long as it is connected to grid power)

Main features
1. LCD digital display show voltage, load and battery information in real time.
2. Peak power is three times of rated power.
3. Can work with inductive loads such as air conditioner, motor door and so on
4. Accept generator's energy output.
5. Pure sine wave output, available for sensitive loads.
6. Microprocessor control with 4-step progressive charging, 7 battery type selector.
7. Fast and powerful charger with 35A and 70A.
8. High power factor 0.9-1.0, low power consumption.
9. Automatically transfer between battery and line modes.
10. Custom-made communication port USB/RS-232/SNMP
11. Remote control function.
12. Protection against overload, over temperature, over charging, low battery.

Parameter

LED Model		LWS1000	LWS1500	LWS2000	LWS3000	LWS4000	LWS5000	LWS6000	LWS7000	LWS8000
LCD Model		LWS1000-C	LWS1500-C	LWS2000-C	LWS3000-C	LWS4000-C	LWS5000-C	LWS6000-C	LWS7000-C	LWS8000-C
Nominal Power		1000W	1500W	2000W	3000W	4000W	5000W	6000W	7000W	8000W
AC Input	Phase & waveform	Single Phase & Pure Sine Wave
	Norminal Voltage	120VAC/230VAC OR 220/230/240VAC
	Acceptable Voltage	95-126VAC OR 194-253VAC±4%
	Line Low Disconnect	85V±4% OR 184±4% (154 wide mode±4%)
	Line Low Reconnect	95V±4% OR 194 ±4%(164 wide mode±4%)
	Line High Disconnect	136V±4%/274±4%
	Line High Reconnect	126V±4%/264±4%
	Frequency	50Hz(41-54) or 60Hz(51-64) (auto sensing)
Output	Phase & Waveform	Single Phase & Pure Sine Wave (bypass mode sync to input)
	Voltage	110/120/130VAC OR 220/230/240VAC±10%rms (bypass mode sync to input)
	Voltage Regulation	±10%rms (bypass mode sync to input)
	Frequency	50Hz±0.3Hz OR 60Hz±0.3Hz (bypass mode sync to input)
	Peak Power	3 times of rating power
	Short Circuit Protection	Yes, shutdown after 10ms
	Power Factor	0.9-1.0
DC Input	Battery Voltage	12/24Vdc	12/24/48Vdc			24/48Vdc			48/72Vdc
	Minimum Start Voltage	10V for 12V, 20V for 24V, 40V for 48V
	Low Battery Alarm	10.5±0.3Vdc for 12V, 21±0.6Vdc for 24V, 42V±1.2for 48V
	Low Battery Transfer	10V±0.3Vdc for 12Vdc, 20V ±0.6Vdcfor 24V, 40V ±1.2Vdcfor 48V
	High Voltage Alarm	16V±0.3 for 12V, 32V ±0.6for 24V, 64±1.2V for 48V
	High DC Input Recovery	15.5±0.3Vdc or 31±0.6Vdc or 62V±1.2Vdc
	Max Charge Current	20A/35A/50A/75A/90A(According to the inverter model)
Transfer Efficiency	Line Mode	>96%
	Battery Mode	>85%
System Parameter	Power Saver	Load<=25W(Enabled on "P/S auto"setting of Remote Control
	Audible Alarm	Souding when the heat sink 's temperature is over 100ºCand shut down after 30 seconds
	Over Load Protection	110%
		Load>150%,beeps 0.5s every 1s,and fault after 20s
	Protections	low battery,over charging,over temp,over load
	Communications	RS-232/USB/SNMP(custom-made)
	Operating Environment	0-40ºC,0-90%RH(non-condensing)
	Audible Noise	<60dB
	Net Weight(KG)	15.5	18	20	25.5	36	39.5	48	55	60
	Dimension, L X W X H(mm)	470×223×185mm				650×223×185mm

Trading terms for reference:
Delivery time: 7-15 workdays after payment
Payment terms: TT, LC, Western Union, Money gram.
Warranty: 2 years, 1%-2% spare parts.
