24V Brushless DC Planetary Gear Motor

Name: 24V Brushless DC Planetary Gear Motor
Brand: all-electronics-online.com
SKU: 774682365
Availability: InStock
Rating: 5 (57 reviews)

Price:	US $ 50/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,Paypal,Money Gram,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	36BL60-36PLG30
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Diameter:	36mm
Voltage:	12/24V
Application:	Power Tools
Operating Speed:	Low Speed
Excitation Mode:	Shunt
Structure And Working Principle:	Brushless
Brand:	Longway

Product Description

Brushless Motor Technical Data

Model	Rated Voltage	No-load speed	No-load current	Rated speed	Rated torque	Output power	Peak torque
Model	V DC	rpm	mA	rpm	mN.m	W	N.m
36BL60-2420	24	2000	90	1600	30	4.8	0.36
36BL60-2440	24	4000	130	3200	48	15.7	1.0

Brushless Gear Motor Technical Data
Model: 36bl60-36plg30

Reduction ratio	3.7	5.2	14	19	27	51	71	100	139	189	264	369
Number of gear trains	1	1	2	2	2	3	3	3	3	4	4	4
Length mm	31.5	31.5	38.5	38.5	38.5	38.5	48.5	48.5	48.5	55.5	55.5	55.5
No-load speed rpm	539	386	143	105	74	39	28	20	14	11	7.6	5.4
Rated speed rpm	431	309	114	84	59	31	23	16	12	9	7	4
Rated torque N.m	0.1	0.14	0.34	0.46	0.66	1.1	1.6	2.2	3	3	3	3
Max. permissible load in a short time N.m	0.9	0.9	3	3	3	6	6	6	6	9	9	9

Welcome your inquiry.

Ningbo Yinzhou Longway Technology Co., Ltd. is a professional motor, machinery and electronic products manufacturer in China. Since day one after its establishment, our company has spared no efforts in developing new products and optimizing them. A comprehensive and consistent quality system has been since long established, from design to production, form marketing to after sale service. Our company attaches great importance to employee training. It pays off when the quality of each and every one of our employees keeps improving. Now the motor products include PMDC motors, brushless motors, stepping motors, AC and DC gear motors, synchronous motors, brushless servo motors. Most of products are CE, UL approved. We can also complete OEM/ODM orders in accordance with clients' specific requirements, designs and samples.

The advanced technologies of design and manufacturing were adopted from Germany. We take pride in the CAD/cam mould tooling center and the testing center. We enjoy an excellent reputation in Europe, America, Australia, Middle East, and southeast Asia as well as in China.

"satisfactory products plus satisfactory services" makes our success happen. We sincerely hope to have and also thank for valuable supports and cooperation from all friends in the world.
