33kv High Voltage Porcelain Pin Insulator

Name: 33kv High Voltage Porcelain Pin Insulator
Brand: all-electronics-online.com
SKU: 740888385
Availability: InStock
Rating: 4.4 (43 reviews)

Price:	US $ 2-5/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	500/Piece
Pay Type:	L/C,T/T,Western Union,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	ANSI P-33-Y
Markets:	North America,South America,Southeast Asia,Africa,Mid East,Eastern Asia
Application:	High-voltage
Material:	Porcelain
Structure:	Pin Insulator
Type:	A Type Insulator

Product Description

ANSI P-33-Y Porcelain Pin Type Insulator
1.Factory price
2.Timely delivey
3.ANSI,CESI,DIN,BS CLASS

BS Class			P-33-Y
Recommended Nominal System Voltage/kV			33
Total Creepage Distance/mm			630
Protected Creepage Distance/mm			381
Recommended Pin Height/mm			280
Cantilever Strength/kN			11
Minimum Flashover Voltage	Power-Frequency	Dry/kV	130
		Wet/kV	85
	50% Impulse	Positive/kV	185
		Negative/kV	260
Radio-Influence Voltage Date	One-minute Power-Frequency	Dry/kV	110
		Wet/kV	75
	Impulse/kV		170
Power-Frequency Puncture Voltage/kV			185
Radio-Influence Voltage Data	Test Voltage to Ground/kV		22	22
	Maximum RIV at 1,000kHz/ μ V		16,000	200

VICCIA Electrical Co., Ltd., a member of Fuzhou Light Industry Co., Ltd, is located in Sanming City of Fujian Province. We specialized in manufacturing and supplying multiple products, particularly in the field of electrical appliance, such as Fiberglass ladder and Aluminum ladder, high and low voltage product, power fittings and so on. Started with the business of international trading and sales agent of domestic supplier and overseas buyer, we now have skilled and experienced engineer team in design and manufacturing, as well as trained talents in business and management which enables us to respond effectively to the demands of market and our customers at all times.

The slogan of VICCIA is to provide the highest quality services to each customer, and to provide products to each customer with reasonable price and good quality. At the same time, we can develop and manufacture gratifying products in accordance with customers' certain requirements.

Put your trust in VICCIA, let us work together and achieve more.
