36mm Brushless DC Planetary Gear Motor

Name: 36mm Brushless DC Planetary Gear Motor
Brand: all-electronics-online.com
SKU: 742013585
Availability: InStock
Rating: 4.6 (42 reviews)

Price:	US $ 35/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	36BL42-36PLG20
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Name:	36mm Brushless DC Planet Gear Motor
Application:	Power Tools
Operating Speed:	Low Speed
Excitation Mode:	Excited
Structure And Working Principle:	Brushless

Product Description

36mm brushless dc planet gear motor,
Brushless Motor Technical Data

Model	Rated Voltage	No-load speed	No-load current	Rated speed	Rated torque	Output power	Peak torque
Model	V DC	rpm	mA	rpm	mN.m	W	N.m
36BL42-2440	24	4000	270	3700	32	7	96
36BL42-2450	24	5000	300	4800	36	10	110

Brushless Gear Motor Technical Data
Model: 36BL40-36PLG20

Reduction ratio	3.7	5.2	14	19	27	51	71	100	139	189	264
Number of gear trains	1	1	2	2	2	3	3	3	3	4	4
Length mm	31.5	31.5	38.5	38.5	38.5	38.5	48.5	48.5	48.5	55.5	55.5
No-load speed rpm	809	579	214	158	111	59	42	30	22	16	11
Rated speed rpm	566	405	150	111	78	41	30	23	18	13	9
Rated torque N.m	0.09	0.13	0.31	0.42	0.59	1	1.4	2	2.7	3	3
Max. permissible load in a short time N.m	0.9	0.9	3	3	3	6	6	6	6	9	9
