48V 120W DC Electrical Motor Asynchronous Motor

Name: 48V 120W DC Electrical Motor Asynchronous Motor
Brand: all-electronics-online.com
SKU: 765630885
Availability: InStock
Rating: 4.9 (31 reviews)

Price:	US $ 49.55-66.06/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	Z5D12024GU-30S/5GU6K
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Dimensions Of Device:	90mm
Power:	120W
Voltage:	24V
No-Load Speed:	3000rpm
Load Speed:	3000rpm
Reduction Ration:	18:1
Brush Life:	2000h
Net Weight:	3.7kg
Packaging Details:	12 PCS in 1 Carton (Optional)
Delivery Tdetail:	15 Days
Application:	Power Tools
Operating Speed:	Constant Speed
Excitation Mode:	Compound
Structure And Working Principle:	Brush
Type:	Other
Certification:	SGS
Brand:	Sy

Product Description

Welcome to our online company

1. It's only the typical data.
The gear motor can be customized if you have some special requirements
such as the gear ratio, torque and shaft dimension.
The motor price is also for reference only and it will be decided by the
reduction ratio and body's length.

2. If you have any questions, pls do not feel hesitate to ask us.
You can send us messages, emails or give us a call.

Features:
1. Dimensions of device: 60mm, 70mm, 80mm, 90mm, 104mm
2. Power: 6W, 15W, 25W, 40W, 60W, 90W, 120W, 250W
3. Voltage: 12V, 24V, 90V, 220V
4. Shape of motor shaft: 1) GN: Genaral Helical Gear
2) A1: Milling Keyway
3) GU: Reinforced Helical Gear
4) A: Flat type
5.Gear type: 1) GN: General Helical Gear
2) GU: Reinforced Helical Gear

The Data Sheets:

Our company is specialized in mirco AC gear motors.
At present, there are three kinds of motors in our company:
1) micro gear motor include AC gear motor and DC gear motor;
2) small AC gear motor;
3) high precision planetary gearbox.

The usages:
They are widely used in machine tools, textile machinery, medical appliance, conveying machines, printing mechanism, food machinery, vending machines, packing machinery, and gumming machines.

The good quality:
With excellent equipment, advanced procedure, scientific management, and modern test method, we can provide all customers both at home and abroad with our top quality products, favorable prices and sincere service.

We hope that we canestablish long-term business relationships together with you for mutual business success.

type	Power W	Voltage V	No-load Parameters		Load Parameters			Brush life H	Motor weight kg
			Speed r/min	Current A	Speed r/min	Torque mN.m	Current A
Z2D(W)	6	12	3200	0.6 Max.	2950	19	0.8	2000	0.6
	6	24	3200	0.3 Max.	2950	19	0.5	2000	0.6
	6	90	3200	0.1 Max	3000	19	0.2	2000	0.6
	15	12	3000	0.7 Max	2800	51	2.0	2000	0.7
	15	24	3200	0.3 Max	2950	48	1.0	2000	0.7
	15	90	3000	0.1 Max	2900	49	0.3	2000	0.7
Z3D(W)	25	12	3300	1.0 Max	3000	80	3.0	2000	1.0
	25	24	3200	0.6 Max	2800	87	1.6	2000	1.0
	25	90	3200	0.2 Max	3000	80	0.5	2000	1.0
Z4D	40	12	3200	2.0 Max	3000	127	5.2	2000	1.8
	40	24	3200	0.8 Max	3000	127	2.1	2000	1.8
	40	90	3100	0.3 Max	2950	129	0.6	2000	1.8
Z5D	40	12	3200	2.0 Max	3000	127	5.2	2000	1.9
	40	24	3000	1.0 Max	2800	140	2.2	2000	1.9
	40	90	3100	0.3 Max	2950	129	0.6	2000	1.98
	60	12	3200	2.0 Max	2950	194	7.5	2000	2.2
	60	24	3100	1.5 Max	2800	210	3.5	2000	2.2
	60	90	3200	0.3 Max	3000	191	1.0	2000	2.2
	90	12	3300	3.0 Max	2800	307	10.0	2000	2.2
	90	24	3100	1.5 Max	2800	307	5.0	2000	2.2
	90	90	3100	0.5 Max	2850	302	1.5	2000	2.2
	120	12	3400	3.0 Max	3000	382	14.0	2000	2.2
	120	24	3300	1.5 Max	2600	441	7.0	2000	2.2
	120	90	3100	0.3 Max	3000	382	1.8	2000	2.2
Z55D	250	24	3600	4.0 Max	3200	746	16.0	2000	3.2
	250	90	3300	2.0 Max	3000	796	4.2	2000	3.2
	250	220	3100	0.2 Max	2800	853	1.5	2000	3.2
Z6D	250	24	3600	4.0 Max	3200	746	16.0	2000	5
	250	90	3300	2.0 Max	3000	796	4.2	2000	5
	250	220	3100	0.2 Max	2800	853	1.5	2000	5

If you have any questions, pls do not feel hesitate to ask us.
You can send us messages, emails or give us a call.
mobile: +86 15925686183

The brief introduction of our company:

Our company supplys different kinds of products. High quality and reasonable price.

We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective.

To perfect our service, we provide the products with good quality at the reasonable price.

The Products Of Our Company:

Our Company Is Specialized In Gear Motors. At Present, There Are Three Kinds Of Motors In Our Company:

1) Micro Gear Motor Include Micro AC Gear Motor And Micro DC Gear Motor;

2) Small AC Gear Motor;

3) Planetary Gear Motor.

The Usages Of Our Products:

They Are Widely Used In Machine Tools, Textile Machinery, Medical Appliance, Conveying Machines, Printing Mechanism, Food Machinery, Vending Machines, Packing Machinery, And Gumming Machines. With Excellent Equipment, Advanced Procedure, Scientific Management, And Modern Test Method, We Can Provide All Customers Both At Home And Abroad With Our Top Quality Products, Favorable Prices And Sincere Service.

You Can Tell Us About Your Requirements, And We Will Help You To Find The Right Type And Model Which Is Suitable For Your Products. Or You Can Also Provide Your Products Information And We Can Help You To Choose The Right Motors For You.

We Hope That We Can Establish Long-term Business Relationships Together With You For Mutual Business Success.

Motor Voltage, Power, And Speed Will Be Customized According To Your Request Under The Allowed Circumstanced Of Adoptable Dimension
