48V 20A Electric Vehicle DC Module Power Supply with Ce, UL

Name: 48V 20A Electric Vehicle DC Module Power Supply with Ce, UL
Brand: all-electronics-online.com
SKU: 726675552
Availability: InStock
Rating: 5 (49 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	GPR4820C
Efficiency:	≥92%
Input Frequency:	45~65Hz
Input Current:	9A
Power Factor:	0.99
Output Voltage:	42~58VDC
Output Current:	20A
Stabilized Voltage Precision:	±1%
Operating Temperature:	-33~55°c
Weight:	≤1.5kg
Storage Temperature:	-50~+80ºC
Output Type:	Single
Warranty:	2 Years
Certification:	ISO
Output Power:	1200W
Input Voltage:	90~280VAC
Brand:	Goldpower

Product Description

48V 20A Electric Vehicle Charger Module is high power density DC charging rectifier module power supply with CE,UL

Features:

1. Ultra high power density up to 25 W/in³, compact structure.

2. Soft-switching technology, high efficiency more than 92%.

3. Leading APFC tech (active power factor correction), power factor > 0.99

4. Multiple protection and safety regulation (CE/UL)

5. Supports hot plugging.

6. Remote control switching

7. Customized output interface available,with communication port RS485

8. Paralleled work available via current sharing bus

9. THD≤5%

10. Wide operating range:-33~+55ºC.

Application:
1. EV charger
2. 48V distributed power system
3. Ethernet
4. Exchange
5. LAN,MAN
6. Sever
7. Indoor wireless
8. Telecom equipment

Specification:

Model	GPR4820C
Power	1200W
Efficiency	≥92%
Input voltage	90~280Vac
Input frequency	45~65Hz
Input current	9A
Power Factor	0.99
Output voltage	42~58Vdc
Output egulationcurrent	20A
Stabilized voltage precision	±1%
Ripple+Noise(Vp-p)	200mV
Operating temperature	-33~+55ºC
Storage temperature	-50~+80ºC
Humidity	5~95%
Cooling	Forced cooling
Acoustic noise	50dB
MTBF	≤150,000 hours
Turn-on time	3~8S
Current-sharing	±5%
Temperature coefficient	±0.02%/ºC
Dimensions(LxWxH)	270x92.75x41.6(mm)
Weight	≤1.5KG
Protection	Input over/voltage,output over voltage,output over current ,output limited current,short circuit,thermal protection,fan failure.

About us:

Shenzhen Gold Power Tech Co., Ltd. Was established in 1995, a leading excellence integrated power supply solutions partner in the industry. There's an independent industrial park with 80, 000 square meters in Pingshan district, Shenzhen, China. With more than 478 employees and many core intellectual property rights. The production capacity of all kinds of power supply is 6 million units every year, products are exported to more than 30 countries and regions over the world. Goldpower has been the national high-tech enterprise after more than 20 years of practice in power supply industry.

Our products cover Telecom, Green Solar Energy, Automobile application electronic and New energy fields formed six core product series, including standard telecom power supply, remote power supply, HVDC, Solar PV(photovoltaic), LED power supply and the car rechargeable power supply, widely used in communications, power electronics, automatic control, railway, military industry, medical treatment, financial self-service, LED, solar power and automobile charging control system.

We are ISO9001 approved enterprise and we can promise you good quality. Welcome to contact us for business cooperation.
