48VDC Telecom Inverter Power/1kVA, 2kVA, 3kVA, 5kVA Pure Sine Wave Inverter
| Price: |
US $ 100-450/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
| Prod Model: |
TI |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| DC Input: |
48VDC |
| DC Input Range: |
40~58VDC |
| AC Output: |
220VAC, 1phase |
| Wave Form: |
True Sine Wave |
| Install: |
19" Rack Mount |
| Height: |
2u |
| Phase: |
Single |
| Power Source: |
Electric Power |
| Application: |
Telecom |
| Brand: |
Jetpower |
Product Description
48VDC Telecom inverter
DC input: 40~58Vdc
AC output: 220Vac
Capacity: 1 to 10KVA
Main Features:
1) 48Vdc input reduces battery load and provide standardize output time
2) Available AC input reduces battery use
3) Direct current filter prevent interference to telecommunication system
4) Friendly LCD display
5) 19'Rack mount design for easy integration
6) Smart interface RS 232 standard
7) Remote control and schedule switch on/off
8) Optional RS485, USB, SNMP interface
9) True sine wave output
10) With isolation transformer.
| Model name | TI- 1000 | TI-2000 | TI- 3000 | TI- 5000 |
| Structure | Low Frequency SPWM |
| Capacity | 1000VA ( 700W ) | 2000VA ( 1400W ) | 3000VA ( 2100W ) | 5000VA(3125W) |
| DC Input | Normal voltage | -48Vdc |
| Voltage range | -40~-57Vdc |
| Wide band noise current | <10% |
| Psophometric noise current | <2‰ |
| AC Input (Optional) | Normal voltage | 115V/230Vac | 230Vac |
| Voltage range | 80~135Vac | 160~270Vac |
| 160~270Vac |
| Frequency range | 50/60Hz±5% |
| Output | Normal voltage | 115V/230Vac | 230Vac |
|
| Voltage Stability | ±2%(Typical) |
| Frequency stability | 50/60±0.5% |
| Wave style | Sine Wave |
| Overload Capacity | 110~150% for 20sec ; >150% Protect at once |
| Indicators | Front panel LED | Line Normal, bypass output, inverter output, overload , abnormity |
| Audible Alarms | Battery low, overload, abnormity |
| Communications | Intelligent Interface | RS232 and contact closure signal or RS485 |
| Compatible O/S | Windows XP/NT,Linux,Novell,Unix,SNMP,HTTP |
| Safety | Meet UL 1012,EN 60950,EN 50091-1-1 |
| EMI | Meet FCC Part 15,Class A |
| EN 55022,Class A/EN 50091-2,Class A |
| EMC | IEC 801-1,2,3,4,5/EN 61000-4-1,2,3,4,5 |
| Environment | Ambient Operation | 3000 Meters Max,0~40 ºC ,0~95% Humidity ( Non-Condensing ) |
| Audible noise ( 1 meter from surface ) | <45dB | <60dB |
| Physical | Dimension (D×W×H ) mm | 450×430×90 | 450×430×135 |
| Net Weight(kg) | 15 | 18 | 23 | 38.3 |
Founded in 1994, POWTECH invested by Taiwan, is an independently owned international corporation dedicating to develop, produce & distribute JETPOWER brand power supplies and OPTELEC brand optical cables.
The first JETPOWER branded online high frequency UPS was developed in 1994. Driven by customer requirements, we have developed OFF LINE UPS, Line-interactive UPS, Industrial Online UPS, outdoor UPS, telecom inverter, power inverter and home inverter. Through a decade of great efforts, we have made our JETPOWER branded power supplies widely applied in the fields of finance, telecom, electric power, petrochemistry, custom and military field etc, and have been honorably commented by clients. Besides, we also cooperate with many famous power supply companies by OED/ODM, and now our products have been sold worldwidely, including Europe, South America, Africa, Middle East, Asia etc.
As the fast development of power supply, We also expand our business to optical cable and accessories. In 2006, we have set up our own OPTELEC brand to develop, manufacture and distribute ADSS cable, OPGW cable, optical cable, Fusion Splicer, OTDR, Terminal tool kit, ADSS fittings, OPGW fittings, link fittings, wire mesh cable tray, preformed cable tray, cable trunking, cable ladders, STG modules, STG magazines and accessories. Till now, our OPTELEC brand optical cable and accessories have been used in more than 20 countries' telecom lines' construction and power transmission lines' construction.
Powtech has passed the ISO9001 international quality system certification and has established a complete quality system from material source, process, assembling to testing. All Powtech products have been approved by KEMA, SGS and CE (LVD/EMC) or by customer-appointed safety agencies.
Not only do we pride ourselves on competitive price, Advanced technology and top quality products but also we have value-added technical support. We can dispatch our engineer to customer's site for site installation and training, Or we can provide online service to solve any problem during installation & operation. On the priniciple that there is no customer too big or too small, Every customer deserves most professional service. POWTECH people anticipate growing and prospering with you, Embarking on a way of success.
