Name: 50 Ohm RF Cable Coaxial Cable LMR400
Brand: all-electronics-online.com
SKU: 749257245
Availability: InStock
Rating: 4.6 (136 reviews)

Price:	US $ 0.3-0.5/Box
Trade Terms:	FOB,CFR,CIF
Min Order:	500/Box
Pay Type:	L/C,T/T,D/P,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	LMR400 Coaxial Cable
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model Number:	Dt-LMR400 Coaxial Cable
Number Of Conductors:	1
Conductor:	2.74mm
Dielectric:	7.24mm
First Shield:	7.39mm
Second Shield:	8.13mm
Jacket:	10.29mm
Application:	Telecommunication
Certification:	RoHS
Model:	LMR400 Coaxial Cable
Brand:	Daytai
Type:	LMR Coaxial Cable

Product Description

50 Ohm RF Cable Coaxial Cable LMR400

LMR400 Coaxial Cable Description

LMR 400 CoaxialCables, Inner Conductor:2.74mm+Dielectric:7.24mm+First Shield:7.39mm+SecondShield:8.13mm+Jacket:10.29mm.Packing:100M or 305M Wood Spool.

LMR400 Coaxial Cable Electrical Characteristics

Item
Impedance(Ω)	50±2
Capacitance(pF/m)	78.40
Velocity of Propagation(%)	85.00
Min Screening Effectiveness(dB)	≥90
Inner Conductor DCR(Ohm/km)	4.60
Outer Shield DCR(Ohm/km)	5.40
Voltage Withstand(Volts DC)	2500.00
Spark Test(VRMS)	5000.00
Installation Temp Range(ºC)	-40ºC~70ºC
Operating Temp Range(ºC)	-40ºC~70ºC

LMR400 Coaxial Cable Attenuation (@20%)

Max Attenuation(dB/100m)	Frequency
	50MHz	2.00
	150MHz	5.00
	220MHz	6.10
	450MHz	8.90
	900MHz	8.90
	1500MHz	16.80
	1800MHz	18.60
	2000MHz	19.60
	2500MHz	22.20
	5800MHz	35.50
VSWR
VSWR Max	800~2500MHz	1.20
	100~480MHz	1.15
	800~1900MHz	1.15
	1900~2500MHz	1.18
