500V 30kw DC Charging Module Switching Power Supply for EV Charger

Name: 500V 30kw DC Charging Module Switching Power Supply for EV Charger
Brand: all-electronics-online.com
SKU: 726674522
Availability: InStock
Rating: 4.7 (55 reviews)

Price:	Negotiable/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	GPR50060A
Efficiency:	≥96.4%
Operating Temperature:	-40~+65ºC
Communication Port:	Can
Power Factor:	0.995
Output Voltage:	200-500VDC
Max. Output Current:	60A
Voltage Regulation:	≤±0.5%
Current Regulation:	≤±0.5%
Thd:	≤3%
Weight:	18kg
Output Type:	Single
Warranty:	2 Years
Certification:	ISO
Output Power:	30kw
Input Voltage:	260-530VAC
Brand:	Goldpower

Product Description

30KW 500V 60A High Efficiency Electric Vehicle Charger Module is world first 30KW high power densdity DC charging rectifier module power supply

Features:

First 30kW single module design in the industry, ultra high power density, reducing the number of modules in parallel, overall reliability improved.
Soft-switching technology, high efficiency up to 95%, full digital DSP control, total harmonic current less than 5%.
Leading APFC tech (active power factor correction), power factor > 0.995
Automatic intelligent current sharing without monitoring, supports intelligent hibernation.
Ultra wide output range, works with the bus, car and other vehicles, featuring BMS auxiliary low-voltage power output;
Supports hot plugging without damage, a module can be replaced within 1min.
Complete isolation and failure protection between input and output terminal, output end equipped with backflow-prevention device.
Compact size, customized design, compatible with multiple protocols, applicable for integrated / split or other types of charger.

Application:
1. EV Charging equipment manufacturers, Charging service providers.
2. Third party charging pile / station operation and maintenance services providers

Specification:

Model	GPR50060A
Power	30KW
Input voltage	265∼530Vac
Input frequency	45~65Hz
Output voltage	200~750Vdc
Max. output current	60A
Power factor	≥0.995
Voltage regulation	≤±0.5%
Current regulation	≤±0.5%
THD	≤3%
Full load efficiency	≥96.4%
Current sharing	≤±5%
MTBF	>400,000 hours
Ripple(Vp-p)	≤±0.5%
Hold-on time	Softing-staring 8S
Operating temperature	-40~+65ºC
Acoustic Noise	≤55dB
Communication Port	CAN
Protection class	IP32
Lightning protection	5KA
Dimensions	460x 87x 450(mm)
Weight	≤18KG
Protection	Input over/ under voltage, phase-lacking, output over voltage,short circuit,over temperature, failure isolation

About us:

Shenzhen Gold Power Tech Co., Ltd. Was established in 1995, a leading excellence integrated power supply solutions partner in the industry. There's an independent industrial park with 80, 000 square meters in Pingshan district, Shenzhen, China. With more than 478 employees and many core intellectual property rights. The production capacity of all kinds of power supply is 6 million units every year, products are exported to more than 30 countries and regions over the world. Goldpower has been the national high-tech enterprise after more than 20 years of practice in power supply industry.

Our products cover Telecom, Green Solar Energy, Automobile application electronic and New energy fields formed six core product series, including standard telecom power supply, remote power supply, HVDC, Solar PV(photovoltaic), LED power supply and the car rechargeable power supply, widely used in communications, power electronics, automatic control, railway, military industry, medical treatment, financial self-service, LED, solar power and automobile charging control system.

We are ISO9001 approved enterprise and we can promise you good quality. Welcome to contact us for business cooperation.
