50W DC-5VDC Converter Switching Power Supply

50W DC-5VDC Converter Switching Power Supply
Price: US $ 11/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,D/P,Paypal,Money Gram
Prod Model: SD-50(A, B, C)-5
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Model 1: SD-50A-5 : 12VDC-5VDC10A
Model 2: SD-50V-5 : 24VDC-5VDC10A
Model 3: SD-50c-5 : 48VDC-5VDC10A
Size: 159*98*38mm
Weight: 0.45kg
Package: 40PCS/18kg
Certificate: CE RoHS ISO9001
Warranty Timer: 12 Months
Power: 50W
Output Type: Single
Warranty: 1 Year
Output Power: 51 - 100W
Input Voltage: Full Range
Connection Mode: Parallel Switching Power Supply
Starting Mode: Self-excited Switching Power Supply
Voltage Regulating Mode: Width Modulation Type
Power Supplying System: Terminal Power Distribution Equipment
Certification: CE
Brand: Smun

Product Description

100W Single Output DC- DC Converter SD-50w series

Features:
2: 1 wide input range
Protections: Short circuit/Over load/Over voltage
1500VDC I/O isolation
Built-in EMI filter, low ripple noise
100% full load burn-in test
Fixed switching frequency at 83KHz
24V and 48V input voltage design refer to LVD
Low cost
High reliability
159*98*38mm (L*W*H)
Model NO.DC outputoutput currentTolerancerangeefficiency
S D - 50(A,B,C) -55V0-10A±2%100mV73%
S D - 50(A,B,C) -1212V0-4.2A±1%120mV75%
S D - 50(A,B,C) -2424V0-2.1A±1%150mV80%
AC input voltage rangeA:9.2-18VDC
B:19-36VDC
C:36-72VDC
input current7A/12V
3A/24V
1.5A/48V
AC inrush currentCold-start current 10A/DC
Leakage current<0.5mA/DC
DC adjustable range±10% rated output voltage
Over load protection105-150%cut down output, auto-recovery
over-voltage protection115-135%
set up, rise,hold up time:2.5ms,50ms......at full load
withstand voltage:I/P-O/P:1.5KVAC 1Minutes
I/P-FG:1.5KVAC 1MInutes
O/P-FG:0.5VAC 1minutes
working temperature-10~+60°C,20-90%RH
weight/packing:0.45kg,40pcs/18kg
Size159*98*38MM
certificateCE  ISO9000 ROHS
Warranty year1 year

Zhejiang Ximeng Electronic Technology Co., Ltd. specialized in designing R&D production and sale. We have Independent import and export rights. The main products are switching power supply, LED driver power supply, AC/DC adapter, Electrical plug&sockets, Indicator lamp, terminal blocks, cable glands and related wiring accessories, Push button switches, and so on. All products are exported by our company YUEQING XIMENG IMP&EXP. Co., Ltd.

Our company is a high-tech company specialized in designing. R&D. Production and sale, the products Switching Power Supply are with the characteristics of the low price, high efficiency, high reliability, long lifetime and so on. Our products are widely used in industrial automation field, indoor and outdoor LED lighting, LED lighting projects, communication, instrumentation, etc. Our Switching Power Supply is the ideal upgraded product to replace traditional controlling transformer. The design of this series of products is in accordance with such international standards as American UL1012, German TUVEN60950, IEC950, UL1950 and EC EMCLVD. Relying on high-quality imported components, advanced production techniques and perfect testing equipment, we create high-quality XIMENG products. XIMENG products sell well in domestic markets and in Europe and Southeast Asia. Our company focuses on innovating science and technology, wining a reputation with quality, and pursuing development with sincerity. We always update our equipment and create new products constantly, striving to follow the core mind of Science and Technology to improve life and supply wide customers with sincerity, high-quality products and highly efficient service. In order to thanks to the long-term support and the cooperation of customers at home and abroad, as well as develop new business field, our company warmly welcomes all the customers to come for instruction and discuss cooperation. Let us develop together and create our prosperous future!
