6/10 (12) Kv XLPE Insulated PVC Sheathed Unarmoured Power Cable

Name: 6/10 (12) Kv XLPE Insulated PVC Sheathed Unarmoured Power Cable
Brand: all-electronics-online.com
SKU: 711242272
Availability: InStock
Rating: 4.7 (80 reviews)

Price:	US $ 0.76-0.8/Meter
Min Order:	1000/Meter
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	10kV cable BM39
Option Conductor:	Aluminum
Application:	Underground
Voltage:	Low and Medium Voltage Cable
Current:	DC & AC
Insulation Material:	XLPE
Certification:	VDE
Brand:	Yifang

Product Description

6/10(12) KV XLPE Insulated PVC Sheathed Unarmoured Power Cable

Single Core (Unarmoured )

Conductor			Conductor screen ( mm )	Nominal Thickness of Insulation ( mm )	Insulation screen ( mm )	Copper screen tape ( mm )	Nominal Thickness of Sheath ( mm )	Approx Overall diameter ( mm )	Approx Weight ( kg/km )	Insulation resistance at 15.6°C (Min.) ( Mohm/km)
Size ( mm2 )	Shape	Outside diameter ( mm )	Conductor screen ( mm )	Nominal Thickness of Insulation ( mm )	Insulation screen ( mm )	Copper screen tape ( mm )	Nominal Thickness of Sheath ( mm )	Approx Overall diameter ( mm )	Approx Weight ( kg/km )	Insulation resistance at 15.6°C (Min.) ( Mohm/km)
16 25 35 50 70	N.C. C.C. C.C. C.C. C.C.	5.10 5.91 6.95 8.05 9.67	0.8 0.8 0.8 0.8 0.8	3.4 3.4 3.4 3.4 3.4	0.8 0.8 0.8 0.8 0.8	0.1 0.1 0.1 0.1 0.1	1.5 1.6 1.6 1.7 1.7	20.5 21.4 22.5 23.7 25.4	552 663 788 935 1183	2200 1700 1500 1400 1200
95 120 150 185 240	C.C. C.C. C.C. C.C. C.C.	11.39 12.33 14.24 15.98 18.32	0.8 0.8 0.8 0.8 0.8	3.4 3.4 3.4 3.4 3.4	0.8 0.8 0.8 1.0 1.0	0.1 0.1 0.1 0.1 0.1	1.8 1.8 1.9 2.0 2.0	27.3 28.8 30.4 32.7 35.2	1485 1763 2064 2498 3122	1100 1000 950 850 780
300 400 500 630	C.C. C.C. C.C. C.C.	20.65 23.33 26.34 30.50	0.8 0.8 0.8 0.8	3.4 3.4 3.4 3.4	1.0 1.0 1.0 1.0	0.1 0.1 0.1 0.1	2.1 2.2 2.3 2.4	37.7 40.6 43.8 48.5	3778 4661 5712 7232	700 650 600 550

Three Core(Unarmoured )

Conductor			Conductor screen ( mm )	Nominal Thickness of Insulation ( mm )	Insulation screen ( mm )	Copper screen tape ( mm )	Nominal Thickness of Sheath ( mm )	Approx Overall diameter ( mm )	Approx Weight ( kg/km )	Insulation resistance at 15.6°C (Min.) ( Mohm/km)
Size ( mm2 )	Shape	Outside diameter ( mm )	Conductor screen ( mm )	Nominal Thickness of Insulation ( mm )	Insulation screen ( mm )	Copper screen tape ( mm )	Nominal Thickness of Sheath ( mm )	Approx Overall diameter ( mm )	Approx Weight ( kg/km )	Insulation resistance at 15.6°C (Min.) ( Mohm/km)
16 25 35 50 70	N.C. C.C. C.C. C.C. C.C.	5.10 5.91 6.95 8.05 9.67	0.8 0.8 0.8 0.8 0.8	3.4 3.4 3.4 3.4 3.4	0.8 0.8 0.8 0.8 0.8	0.1 0.1 0.1 0.1 0.1	2.1 2.3 2.4 2.5 2.6	42.2 44.1 46.7 49.3 53.0	1833 2188 2597 3074 3872	2200 1700 1500 1400 1200
95 120 150 185 240	C.C. C.C. C.C. C.C. C.C.	11.39 12.33 14.24 15.98 18.32	0.8 0.8 0.8 0.8 0.8	3.4 3.4 3.4 3.4 3.4	0.8 0.8 0.8 1.0 1.0	0.1 0.1 0.1 0.1 0.1	2.8 2.9 3.0 3.1 3.3	57.0 60.4 63.6 68.6 74.0	4838 5732 6694 8090 10080	1100 1000 950 850 780
300 400	C.C. C.C.	20.65 23.33	0.8 0.8	3.4 3.4	1.0 1.0	0.1 0.1	3.4 3.7	79.4 85.7	12170 14976	700 650

Zhengzhou Yifang Cable Co., Ltd is a large joint-stock\hi-tech enterprise established in 1988. We are specialized in wires & cables, including designment, production and sales.

There are more than 500 staffs in our factory including over 50 technical personnel, 5 senior engineers. With complete advanced cable producing equipments over 150 sets, complete testing equipments, a national level fire-resistant & flame retardant cable laboratory. Our technology has reached advanced levels at home and abroad.

Our main products include: Power Cable for voltage up to 220KV, Overhead insulated cable, ABC Cable, Building Cable and flexible cord, Control Cable, Rubber Cable, Bare Conductor(ACSR, AAC, AAAC, BCC), Welding Cable, Galvanized Steel Wire(Stay wire), flame retardant mining cable, etc

We have own IM/EX right, our products have been exported to Europe, Australian, Middle-east, South-east Asia, Africa, American, South American etc., being subjected to consistent good opinion of customers.
