0.6/1kv PVC 1/2/3/4/5 Core Insulated PVC Sheathed Low Voltage Cable Waterproof Electrical Cable

Name: 0.6/1kv PVC 1/2/3/4/5 Core Insulated PVC Sheathed Low Voltage Cable Waterproof Electrical Cable
Brand: all-electronics-online.com
SKU: 691275591
Availability: InStock
Rating: 4.7 (71 reviews)

Price:	US $ 0.1-30/Meter
Min Order:	100/Meter
Pay Type:	L/C,T/T,D/P,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	0.6/1kV PVC 1/2/3/4/5 core power cable
Product Name:	0.6/1kv PVC 1/2/3/4/5 Core Power Cable
Rated Voltage:	0.6/1 Kv
Conductor:	Copper
Insulation:	XLPE / PVC
Sheath:	PVC
Core Number:	1 2 3 4 5
Color Color:	Red , Yellow , Blue ,Green or as Your Requirement
Origine:	Shandong , China
Packaging:	Wooden Drum
Shipping:	3-10 Working Days
Application:	Power Station
Voltage:	Low and Medium Voltage Cable
Current:	DC & AC
Insulation Material:	XLPE
Certification:	VDE
Model:	XLPE Power Cable
Brand:	Chan Qing Teng

Product Description

1. Main Application

PVC insulated cables are used in power distribution and transmission, building wire, appliance wiring, flexible cord
and machine tool wiring. Insulation and jackets made from PVC have a number of desirable properties that make them
the insulation and jacketing material of choice for many common applications. These properties include flexibility,
resistance to temperature, resistance to adverse environmental situations and low cost.

2. Standards

GB/12706-2008, ASTM, IEC60502, BS, DIN, AS/NZS and ICEA or as customer required.

3. Product Properties

(1) Max. continuous operating temperature of conductor is 70ºC.

(2) Short (the longest duration of no more than 5s) maximum operating temperature of cable conductor is:
cross-section ≤ 300 mm2, 160 ºC; cross section> 300 mm2, 140 ºC.

(3) The installation temperature should not over 0ºC,if the ambient temperature is lower than 0ºC,the cable
should be preheated ,the bending radius of cable should not less than10-20 times.

4. Product Type

Chinese Type		Designation	Application
Cu	Al	Designation	Application
VV	VLV	Cu core(Al core)PVC insulated PVC sheathed power cable	Laying indoors, in tunnel, fixed on the bracket, pipe and buried in the soil, the cable can not bear external mechanical forces.
VY	VLY	Cu core(Al core)PVC insulated PE sheathed power cable
VV22	VLV22	Cu core(Al core)PVC insulated double of steel-tape armored PVC sheathed power cable	For laying indoors, in tunnel, cable trench, or direct in ground, able to bear external mechanical forces, but unable to bear large pulling force.
VV23	VLV23	Cu core(Al core)PVC insulated double of steel-tape armored PE sheathed power cable
VV32	VLV32	Cu core(Al core)PVC insulated steel-wire armored PVC sheathed power cable	For laying indoors, in tunnel, cable trench, well or direct in ground, able to bear external mechanical forces and certain pulling force.
VV33	VLV33	Cu core(Al core)PVC insulated steel-wire armored PE sheathed power cable

Note: Our manufacture can produce flame retardant, fire resistance, termite-type; low smoke zero halogen,
low smoke halogen type and other types of cables according to customer requirements.

5. Consturction

Conductor: Annealed plain Copper or Aluminium

Insulation: PVC Compound Insulation

Colour Code (1):

1 Core: Red or Black

2 Cores: Red, Black

3 Cores: Red, Yellow, Blue

4 Cores: Red, Yellow, Blue, Black

5 Cores: Red, Yellow, Blue, Black, Green

Above 5 Cores: Black Cores with White numerals

Colour Code (2):

1 Core: Brown or Blue

2 Cores: Brown, Blue

3 Cores: Brown, Black, Grey

4 Cores: Blue, Brown, Black, Grey

5 Cores: Green/Yellow, Blue, Brown, Black, Grey

Above 5 Cores: Black Cores with White numerals

Bedding /Inner Sheath :PVC Compound

Armour:Aluminium wire, Galvanized steel wire or Steel tape

Outer Sheath:PVC Compound

Note: The armored material of single core cable should be non-magnetic or magnetic reduced structure.
Generallly, single core armored cable (which uses steel or steel wire armored cable) only applies to DC
occasions.

Luxing Factory : our production base

Luxing Cable Mainly Produce

300/500V 450/750V electrical wire	AAC conductor
600/1000V PVC insulated cable	AAAC conductor
600/1000V XLPE insulated cable	ACSR conductor
1.8/3KV to 26/35KV power cable	OPGW
Armored underground cable	ABC cable
Control cable and instrumentation cables	Rubber cable

Certificates

Strict Quality Test

Packaging & Shipping

Our Advantage

Design wire and cable according to your real application

Optimized reel size for freight cost saving

Customized package to feature your brand

Short lead time to meet your urgent demand

Diversified delivery terms for your options

Quick response (24 hours on line)

Professional knowledge for clear answer to your any question

Comprehensive technical documents to support your tender bidding

One-year limited warranty for our wire and cable

Cable sample available

Specify the cable only according to the location

OEM is available

Abundant cables and wires for your option

Trade Assurance by Alibaba

1) About Luxing Cable Factory:

-Shandong New Luxing Cable Co., Ltd established in the year of 1999.

-The headquarter is located in Jinan City, the capital of Shandong province, China.

-Registered capital of USD16.5 million, Legal representative Wang Xiuzhen.

-Luxing Cable Factory is located in Linyi Economic Development ZoneCovering an area of more than 60 acres.

-Shandong New Luxing Cable Co., Ltd has more than 150 employees, which college degree more than 50 people.

2)Why Choose Luxing Cable Factory?

-Luxing cable, the designated supplier of China's national grid construction.

-We provid high-quality cables for our clients for more than 18 years.

-The professional, safe and reliable of Luxing factory gained great trust and praise from our customers.

-Serve you any time.

3)The Product of Luxing Cable Factory

-300/500V 450/750V electrical wire

-600/1000V PVC insulated cable

-600/1000V XLPE insulated cable

-1.8/3KV to 26/35KV power cable

-Armored underground cable

-Control cable and instrumentation cables

-ABC cable

-AAC conductor

-AAAC conductor

-ACSR conductor

-OPGW

-Rubber cable

4)Product application

-Used for open air installation, for direct burrial underground, in water, in cable ducts, power stations, for industry and distribution boards and so on.

-Power transmission and distribution project bids we can work, cable retail and wholesale, regional agent we can cooperate.

5)Production Market

-Supply power cables & electrical wire to

South America(Brazil...),

East Asia(Korea...),

Africa(Uganda, South Africa, Zimbabwe...),

Southeast Asia(Myanmar, Thailand, Indonesia, Philippines, Malaysia, Cambodia...),

Europe(Czech Republic...) to global market.

-Had fixed partnership with SGCC&STATE GRID CORPORATION OF China (China largest power enterprise) and many other our country State-owned big enterprise.

6)Our service

-We guarantee that we will comply with the requirements of warranty period specified in the contract, that the Goods supplied under the purchase order For Procurement of self-carrying distribution network's cable and wire.

-We will be manufactured under this specification and that the Goods will be new, unused, of the most recent or current models. Once we are selected, we will supply the Goods strictly according to the requirements of the Contract.

-The warranty shall remain valid for twelve (12) months after the Goods, or any portion thereof as the case maybe, have been delivered to and accepted at the final destination indicated in the SCC, or for eighteen (18) months after the date of shipment from the port or place of loading in the country of origin, whichever period concludes earlier.

-During the warranty period purchaser may proclaim directly to the manufacturer in the written form or by the agent if there is any problem in Goods quality. The manufacturer will do the repair or replacement in reasonable time, and will bear all the expenses relating to this.
