600-1000watt Inverter& MPPT & Charger

Name: 600-1000watt Inverter& MPPT & Charger
Brand: all-electronics-online.com
SKU: 794382425
Availability: InStock
Rating: 4.3 (35 reviews)

Price:	US $ 40/Piece
Min Order:	100/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	WSP-hp01

Product Description

600-1000Watt Inverter& MPPT & Charger
♦ Smart Remote Control
♦ Support Solar Panel with MPPT Function
♦ Designed to Operate under Harsh Environment
♦ DC Start & Automatic Self- Diagnostic Function
♦ Compatible with Both Linear & Non-Linear Load
♦ Easy to Install & Easy to Operate & Easy to Solve
♦ Low DC Voltage Supports Home & Office Appliances
♦ Powerful Charge Rate Up to 120Amp, Selectable From 0%-100%
♦ High Efficiency Design & "Power Saving Mode" to Conserve Energy
♦ Battery Priority Mode, Designates the Inverter-Preferred UPS Configuration
♦ 13 Vdc Battery Recover Point, Dedicated for Renewable Energy Systems
♦ 8 Pre Set Battery Type Selector Plus De-sulphation for Totally Flat Batteries
♦ 4-step Intelligent Battery Charging, PFC (Power Factor Correction) for Charger
♦ 8 ms Typical Transfer Time Between Utility & Battery, Guarantees Power Continuity
♦ 15s Delay Before Transfer when AC Resumes, Protection for Load when Used with Generator

Inverter Output	Rated Power	600W	1000W
	Continuous output power	600W	1000W
	Surge rating(20s)	1800W	3000W
	Output Waveform	Pure sine wave/same as input (bypass mode)
	Nominal Efficiency	80%peak
	Inverter Efficiency(Peak)	>80%
	Line Mode Efficiency	>95%
	Power Factor	0.9-1
	Nominal Output Voltage RMS	120VAC or 230VAC
	Output Voltage Regulation	±10%RMS
	Output Frequency	50/60±0.3Hz
	Short Circuit Protection	Yes, Current Limit Function(fault after 1sec)
	Typical Tranfer Time	10ms(Max)
	THD	Typical<3%,Max 10% under full linear load
DC Input	Nominal Input Voltage	12VDC
	Minimum Start Voltage	10VDC
	Low Battery Alarm	10.5VDC/11VDC
	Low Battery Trip	10VDC/10.5VDC
	High Voltage Alarm&Fault	16VDC
	High DC input Recovery	15.5VDC
	Low Battery Voltage Recover	13VDC
	Idle consumption-search Mode	<25W when power saver on
AC charge	Input Voltage Range	Narrow: 100~135VAC/194~243VAC
		Wide:90~135VAC/164~243VAC
	Input Frequency Range	Narrow: 47~55±0.3Hz for 50Hz, 57~65±0.3Hz for 60Hz
		Wide:43±0.3Hz plus for 50Hz/60Hz
	Output Voltage	Depends on battery type
	Charger breaker rating(120Vac)	7A	10A
	Max Charge Rate	20A to 25A +/-5A,depending on models
	Over Charge Protection Shutdown	15.7V for 12VDC
	Battery type	Fast VDC	Float VDC
	Gel U.S.A	14	13.7
	AGM1	14.1	13.4
	AGM2	14.6	13.7
	Sealed lead Acid	14.4	13.6
	Gel Euro	14.4	13.8
	Open Lead Acid	14.8	13.3
	Calcium	15.1	13.6
	De-sulphation	15.5 for 4hours
	Remote Control	Yes, Optional
Bypass& protection	Input Voltage Waceform	Sine wave(Grid or Generator)
	Nominal Voltage	120VAC	230VAC
	Low Voltage Trip	80V/90V±4%	184V/154V±4%
	Low Voltage re engage	90V/100V±4%	194V/164V±4%
	High Voltage Trip	140V±4%	253V±4%
	High Voltage re engage	135V±4%	243V±4%
	Max input AC voltage	150VAC	270VAC
	Nominal Input Frequency	50Hz or 60Hz (Auto detect)
	Low Freq Trip	Narrow:47±0.3Hz for 50Hz,57±0.3Hz for 60Hz
		Wide:40±0.3Hz for 50Hz/60Hz
	Low Freq re engage	Narrow:48±0.3Hz for 50Hz, 58±0.3Hz for 60Hz
		Wide: 45±0.3Hz for 50Hz/60Hz
	High Freq Trip	Narrow:55±0.3Hz for 50Hz, 65±0.3Hz for 60Hz
		Wide: No up limit for 50Hz/60Hz
	High Freq re engage	Narrow:54±0.3Hz for 50Hz, 64±0.3Hz for 60Hz
		Wide:No up limit for 50Hz/60Hz
Mechanical Specifications	Dimensions(WHD)	325173135mm	362173135mm
	Net weight (kg)	7.5KG	11KG
	Shipping Dimensions(WHD)	425230205mm	475230205mm
	Shipping Weight (kg)	8.5KG	12KG
* Product specifications are subject to change without further notice
