6000W Pure Sine Wave DC to AC Powerstar W7 Inverter
| Price: |
US $ 100-600/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
10/Piece |
| Pay Type: |
T/T,Western Union,Money Gram |
| Prod Model: |
LW1000W-LN6000W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Built In Charger: |
35AMP/70AMP |
| Color: |
White, Black |
| Capacity: |
1kw-6kw |
| DC Voltage: |
12V, 24V, 48V |
| AC Voltage: |
120VAC/220VAC |
| Protection: |
Short Circuit |
Product Description
6000W Pure Sine Wave DC to AC Powerstar W7 Inverter
Powerstar inverter charger 1KW-6KW, 12v/24v/48vdc, pure sine wave inverter, 220vac/110vac (LN series)
PSW7 series ( Professional grade ) inverter charger is designed with the highest standards and is for connecting middle power consumption appliance with extraordinary reliable performance.
The charger current is about 70A with pure sine wave output. The capacity have 1000W to 6000W.
The most important function is, that inverter can work for perceptual load such as air conditioner, laser printer, water pump and some other big momentary currents machine, all home, car ship equipment, normal inverter cannot do that.
Second, the charger circuit can reach up to 70 AMP, and normal inverter only have 10 AMP.
Third, It can work for 50 Hz as well as 60 Hz as it have auto detection the frequency function.
Fourth, it have remote control function, this inverter can use in Car, Ship, Home and so on, and work with 8 kinds of battery and also have power save mode. It can work for solar system.
| Powertar inverter (Rated Output Power) | 1000w | 2000w | 3000w | 4000W | 5000w | 6000w |
| Input Voltage Waveform | Pure Sine Wave (utility or generator) |
| Nominal Input Voltage | 230Vac |
| Low Line Disconnect | 184Vac±4% |
| High Line Disconnect | 253Vac±4% |
| Max AC Input Voltage | 270Vrms |
| Nominal Input Frequency | 50Hz/ 60Hz (Auto detection) |
Over-Load Protection
(SMPS load) | Circuit breaker |
| Output Short Circuit Protection | Circuit breaker |
| Efficiency (Line Mode) | >95% |
| Transfer Switch Rating | 30A |
Transfer Time
(Ac to Dc) | 20ms (typical) |
| Output Voltage Waveform | Sine wave |
| Power Factor | 0~1.0 |
| Nominal Output Voltage (V) | 230Vac |
| Output Voltage Regulation | ±10% rms |
| Nominal Efficiency | >80% |
| Nominal DC Input Voltage | 12V/24V | 12V/24V | 12V/24V/48V | 24V/48V | 24V/48V | 24V/48V |
| Nominal Charge Current | 35A | 35A | 35A | 70A | 70A | 70A |
| Charge Current Regulation | ± 5Adc |
| Batteryinitial voltage | 0 -15.7 Vdc (can operate with 0V battery) |
| Communication: | RJ11 (Used for factory testing. No customer interface available) |
| Safety Certification | Compliance with UL458 | CE(EN60950) |
| EMI Classification | FCC, CLASS A | EN50091-2, CLASS A |
| Operating Temperature Range | 0°Cto 40°C |
| Storage temperature | -15ºC ~ 60ºC |
| Operation humidity | 5% to 95% |
| Audible Noise | 60dB max |
| Cooling | Forced air, variable speed fan |
About ZLPOWER
Founded in 2007, Shenzhen ZLPOWER Electronics Co., Ltd. (ZLPOWER for short) is a key hi-tech enterprise in state "Torch Plan, " integrating science, industry, trade, and investment into a whole. It has registered capital of RMB 10million, covering a floor area of 2000sq. M, and owning assets of RMB 30 million.
As a large-scale enterprise group with total assets exceeding RMB 30 million, it currently employs more than 300 staff, operates R & D institutions, 10 products lines, and 8 overseas branches and offices for sales and service.
Also as a professional uninterruptible power supply manufacturer in Shenzhen, China, ZLPOWER mainly produce high frequency online UPS, computer PC UPS, rack mount online UPS, low frequency Industry three phase UPS, UPS Inverter, solar inverter, solar charger controller, Solar/UPS Battery and other related products.
In ZLPOWER, we are strictly on quality inspections. We implement strict IOC, IPQC, FQC, OQC, QA, and other quality control measures in every process according to ISO9001, including to raw materials selection, production, package, and shipment.
Thus, we are ISO9001: 2008 and SGS certificated, and all our UPS, Inverter power supply products have been approved by CE (LVD/EMC), UL tests. As a result, they are popular among our customers from Italy, Germany, South Africa, Egypt, Mozambique, Nigeria, UAE, Ukraine, Russia, Uzbekistan, Philippines, Chili, Peru, Brazil, Mexico and more.
ZLPOWER is looking for agent worldwide to distribute our quality UPS system, Inverter power and solar products to their local markets. Any interests please welcome to contact us today and look for best power solution.
