60W 5V/12A 12V/5A 15V/4A 24V/2.5A AC/DC Switch/Switching Mode Power Supply
| Price: |
US $ 5.5-10/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,Paypal,Western Union |
| Prod Model: |
S-60W |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Warranty Time: |
24 Months |
| OEM, ODM: |
Accepted |
| Type: |
Single Output |
| OEM: |
Accepted |
| Materail: |
Aluminum |
| Size: |
159*98*38mm |
| Efficiency: |
82% |
| Workig Temperature: |
-10~+50 Degree |
| Sample Lead Time: |
Within 1 Working Days |
| Output Type: |
Single |
| Warranty: |
>2 Years |
| Output Power: |
51 - 100W |
| Input Voltage: |
110-220V |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Self-excited Switching Power Supply |
| Voltage Regulating Mode: |
Width Modulation Type |
| Power Supplying System: |
Level 1 Power Distribution Equipment |
| Certification: |
RoHS |
| Brand: |
Jyins |
Product Description
60w 5v/12a 12v/5a 15v/4a 24v/2.5a ac/dc Switch/Switching mode Power Supply
1. Our company is a professional manufacture and OEM.
2.Our products obtain CE and ISO9001 Certificate and according to IEC 521 international standard to.
3. Low price and high reliability
4.105 C output capacitor
5.AC input power suitable for the world
6.Hight efficiency and low operation temperature
7.Soft-start current can reduce the AC input impact effecticly
8.With Short-circuit and owwerload protection
9.Compact size, light weight
10.100% full-load burning test
11.Installed with EMI filter, minimum waveTechnical Parameters| Model | S-60-5 | S-60-12 | S-60-15 | S-60-24 |
| DC output voltage | 5V | 12V | 15V | 24V |
| Rated output current | 12A | 5A | 4A | 2.5A |
| Output current rage | 0-12A | 0-5A | 0-4A | 0-2.5A |
| Wave and noise | 75mVp-p | 100mVp-p | 100mVp-p | 100mVp-p |
| Inlet stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Load stablity | ±1% | ±0.5% | ±0.5% | ±0.5% |
| Efficiency | 71% | 78% | 78% | 82% |
| Adjustable range for DC voltage | ±10% | ±10% | ±10% | ±10% |
| AC input voltage range | AC100~240V 47~63Hz;240~370VDC |
| Input current | 2A/115V 1A/230V |
| AC INnrush current | Cold-start current 18A/115V 36A/230V |
| Overload proctection | 105%~150% Tpye:Foldback current limiting Reset: auto recovery |
| Over-voltage protection | |
| Setup rise hold up time | 200s,100ms,20ms |
| Withstand voltage | Input and output internal 1.5KVAC,Input and enclosure 1.5KVAC,Output and enclosure 0.5KVAC |
| Isolation resistance | Input and output internal Input and enclosure,Output and enclosure 500VDC/100MΩ |
| Working temperature | -10°C~+50°C |
| Overall dimension | 159*97*38mm |
| Safety standards | Meet ULGB4943 UL60950 EN60950 requirement |
| EMC standards | Meet EN55022 GB9254 class A requirement |
| Weight | 0.55Kgs |
Low price and high reliability105 output capacitorAC input power suitable for the worldHight efficiency and low operation temperatureSoft-start current can reduce the AC input impact effecticlyWith Short-circuit and owwerload protectionCompact size, light weight100% full-load burning testInstalled with EMI filter, minimum wave.
