71mm Pm DC Planetary Gear Motor for Garden Tools

Name: 71mm Pm DC Planetary Gear Motor for Garden Tools
Brand: all-electronics-online.com
SKU: 774137985
Availability: InStock
Rating: 5 (96 reviews)

Price:	US $ 35/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	71ZYT110-72PLG850
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Motor Diameter:	71mm
Premissible Load Range:	1n.M-30n.M
Application To:	Electric Garden Tools and Automatic Mover , Robot
Special Motor:	Small Size , High Torque , Easy Control etc
Application:	Power Tools
Operating Speed:	Constant Speed
Excitation Mode:	Excited
Structure And Working Principle:	Brush

Product Description

71ZYT110-72PLG850               PMDC PLANET GEAR
                                                                      MOTOR
Description of the product
1. Diameter 72mm gearbox has a rated load of 85NM
2. Motor wire can also comes at the bottom of the motor, if no remarks, manufacturer can do in either way.
Motor Technical Data

Model	Rated Voltage VDC	No-load Speed r/min	No-load Current mA	Rated Speed r/min	Rated Torque mN.m	Output Power W	Pated Current mA	Stall Torque mN.m	Stall Current A
71ZYT110-2420	24	2000	0.4	1600	0.20	33	2.4	1.0	9.5
71ZYT110-2430	24	3000	0.5	2400	0.24	59	3.5	1.2	14

Gear motor Technical Data
71ZYT110-2420

Reduction ratio	4	7	14	19	27	35	46	68	82	100	124	150	195	308
Number of gear trains	1	1	2	2	2	2	3	3	3	3	3	3	3	3
Length(L) mm	56	56	75.5	75.5	75.5	75.5	75.5	95.5	95.5	95.5	95.5	95.5	95.5	95.5
No-load speed r/min	500	286	143	105	74	57	43	29	24	20	16	13	10	6
Rated speed r/min	400	229	114	84	59	46	35	24	20	16	13	11	8	6
Rated torque N.m	0.7	1.3	2.3	3.1	4.4	5.7	7.5	9.9	12.	15	18	22	28	45
Max.permissible load in a short time	25	25	85	85	85	85	85	170	170	170	170	170	170	170

71ZYT110-2430

Reduction ratio	4	7	14	19	27	35	46	68	82	100	124	150	195	308
Number of gear trains	1	1	2	2	2	2	2	3	3	3	3	3	3	3
Length(L) mm	56	56	75.5	75.5	75.5	75.5	75.5	95.5	95.5	95.5	95.5	95.5	95.5	95.5
No-load speed r/min	750	429	214	158	111	86	65	44	37	30	24	20	15	10
Rated speed r/min	600	343	171	126	89	69	52	35	29	24	19	16	12	8
Rated torque N.m	0.9	1.5	2.7	3.7	5.2	6.8	8.9	12	14	18	22	26	34	54
Max.permissible load in a short time	25	25	85	85	85	85	85	170	170	170	170	170	170	170

*The specifications can be designed according to the customer's requirement !
