75 ohm Telecom Coaxial Cable BT3002 / 16 Core

Name: 75 ohm Telecom Coaxial Cable BT3002 / 16 Core
Brand: all-electronics-online.com
SKU: 609862915
Availability: InStock
Rating: 4.4 (117 reviews)

Price:	Negotiablekm
Trade Terms:	By Sea
Min Order:	10km
Pay Type:	L/C,T/T

Contact Supplier

Showroom Product Company Profile

Prod Model:	BT3002 - 16 Core
Shield:	double braid
Application:	RF Cable
Conductor Material:	Copper
Cover Material:	PVC
Certification:	RoHS

Product Description

BT3002 / 16 CORE

DESCRIPTION
Single BT3002 Specification:

Conductor: 0.31mm Bare Copper
Dielectric: 1.95mm Solid polyethylene
Shield: 1 layer- Tinned Copper 91% coverage
2 layer - Tinned Copper 90% coverage
Jacket: 3.55 mm white PVC
Overall Diameter: 19.5mm

Electrical Characteristics

Capacitance (pF/m)		66.0
Impedance (Ω)		75+/-4
Velocity of Propagation (%)		67.0
Dielectric Strength (kV rms/min)		3.5
Conductor DCR (Ohm/km)		236.0

Attenuation ( @ 20 ºC)

Frequency (MHz)	Max Attenuation (dB/100ft)	Max Attenuation (dB/100m)
1	0.7	2.3
4	1.4	4.5
5	1.5	4.8
17	2.8	9.2
70	5.7	18.7
100	6.9	22.5
200	9.8	32.0

APPLICATION:

BT3002 Cable are mainly used for indoor installation in the transmission equipments for the digital telephone exchange system. Due to their miniature size they can also be used for other applications where high performance is essential.

Hangzhou Hongsen Cable Co., Ltd. was established in 2002, a manufacturer specializes in RF & Microwave Coaxial Cables. mainly serving the defense, telecommunications, satellite, test and measurement markets.

Our products cover wireless RF Transmission cable, Mini Coax cable, Semi-Rigid, Semi-Flexible Microwave cable, RG MIL-C-17 Spec Cables, CCTV, CATV/MATV cable, satellite cable, video cable. Besides the standard cable, customer required cables are also available in our company.

Quality Control

Hongsen has developed a comprehensive quality assurance program and quality system. This program and system establishes controls throughout the entire manufacturing cycle -- from raw material purchasing and product manufacturing to end-item delivery. It also assures meeting quality objectives and minimizes the possibility of compromises which could affect product quality and reliability. The quality assurance program is complete and responsive to all requirements of ISO9001: 2000.
