75W DIN Rail Series Switching Power Supply (SMPS)

75W DIN Rail Series Switching Power Supply (SMPS)
Price: Negotiable/Piece
Trade Terms: FOB,CFR,CIF
Min Order: 1/Piece
Pay Type: L/C,T/T,Western Union
Prod Model: DR-75W
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Power: 75W
Input Voltage Range: AC85-264V; 120-370VDC
DC Output: 12V 6.3A,15V 5A,24V 3.2A,48V 1.6A
Dimension: 55.5X125.2X100mm
Weight: 0.6kg
Output Type: Single
Warranty: 1 Year
Output Power: 51 - 100W
Input Voltage: 110-220V
Connection Mode: Series Switching Power Supply
Starting Mode: Self-excited Switching Power Supply
Voltage Regulating Mode: Width Modulation Type
Power Supplying System: Level 2 Power Distribution Equipment
Certification: RoHS
Brand: Trihero/OEM

Product Description

Switching power supply DIN Rail Power Supply (SMPS) 75W

Features:
For AC power supply input global
Protection characteristics: short circuit/overload/pressure
Air cooling
Can be installed DIN standards guide TS-35/7.5 or 15
Has the boot display (light emitting diode (led)
100% full load and machine test
Working frequency 50 KHz
One year warranty
Size: 55.5 * 125.2 * 100 mm (W * H * D)

Specification:

model

DR-75-12

DR-75-24

HDR-75-48

output

Dc output voltage

12V

24V

48V

Output voltage tolerance

±2%

±1%

±1%

Rated output current

6.3A

3.2A

1.6A

Output current range

0-6.3A

0-3.2A

0-1.6A

Output power

76W

76.8W

76.8W

Ripple and the noise

100mVp-p

150mVp-p

240mVp-p

Dc voltage adjustable scope

17%

17%

10%

Start, rise time

1000ms,60ms/230VAC Loaded with 1800ms,60ms/115VAC Loaded with

Keep time

60ms/230VAC12ms/115VAC Loaded with

input

Input voltage range

85~264 VAC choose 47~63 Hz;120~370VDC

Exchange input current

1.6 A/115 V 0.96A/ 230 V

efficiency

76%

80%

81%

Impulse current

Cold start current 20A/115V 40A/230V

Leakage current

<1mA/240VAC

Protection characteristics

Overload protection

105%~150%

Protection way: constant current limiting automatic recovery

Overvoltage protection

120%~140%

Protection way: hiccups, auto recovery mode

High temperature protection

TSW1≥85ºC±5ºC,

Protection way: cut output, temperature down automatically restored

environment

Working temperature, humidity

-10ºC~+60ºC;20%~90 %RH

Keep temperature, humidity

-20ºC~+85ºC;10%~95 %RH

Vibrate resistance

10 ~ 500 Hz ac, 2 G 10 min. / 1 cycle time, 60 minutes, the axis

security

Compression sex

3: KVAC between input and output and input and output KVAC: 1.5 to 0.5: KVAC

Insulation resistance

Between the input and output, the input and output, and ground: 100 M / 500 VDC Ohms

Complies with the standards

Safety standards

UL508,TUV EN60950-1

EMC standard

EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,ENV50204,EN55024,EN61000-6-2

other

weight

0.6Kg

packaging

20pcs/13Kg/1.1CUFT

note

1. All the parameters in has not specified, all is in 230 VAC voltage input, rated load and 25 ºC conditions measuring income value.

2. Ripple and noise voltage is in 20 MHz bandwidth oscilloscope take 12 inches twisted pair end with 0.1 mu and 47 u when capacitance measurement.

3. Tolerance is voltage setting error, the voltage adjustment rate and adjust the sum total of the current rate.

4. The power to consider as a device installed in final equipment, this equipment must be to make sure it's EMC index.
