Bicheng Enterprise Limited >> 8 Layer Multilayer PCB 1 Oz Copper Board Immersion Gold

8 Layer Multilayer PCB 1 Oz Copper Board Immersion Gold

8 Layer Multilayer PCB 1 Oz Copper Board Immersion Gold
Price: US $ 0.84/Piece
Min Order: 1/Piece
Pay Type: T/T,Western Union,Paypal
Prod Model: BIC-446-V4.46
Outer Copper Foil: 1 Oz
Board Thickness: 1.6mm
Surface Treament: Immersion Gold
Solder Mask: Green
Legend: White
Min Line Width (Mil): 0.2 Mil
Min Line Spacing (Mil): 0.21 Mil
Electrical Test: 100% PCB Passed
Thermal Shock Test: Pass, No Delamination, No Blistering.
Solderability Test: Pass, 5 Seconds Wetting Area Least 95%
Type: Rigid Circuit Board
Dielectric: FR-4
Material: Fiberglass Epoxy
Flame Retardant Properties: V0

Product Description

Multilayer PCB 8 Layer circuit board TAIYO IJR-4000 MW300 Silkscreen


Commodity Introduction
This is a type of 8 layer multilayer PCB board at 1.6mm thick for the application of Wireless
Communication. The base laminate is from ITEQ Tg170 FR-4, Green solder mask and White
silkscreen from TAIYO on board. It's fabricated per IPC 6012 Class 2 using supplied Gerber
data. Each 20 panel boards are packed separately.



Parameters & Data Sheet
Number of Layers8
Board TypeMultilayer PCB
Board Thickness1.6mm +/-0.16
Board MaterialFR-4
Board Material SupplierITEQ
  170ºC

PTH Cu thickness≥20um (See hole wall details)
Inner Iayer Cu thicknes35 um (1oz)
Surface Cu thickness35 um (1oz)

Solder Mask Type and Model No.LPSM,SR-2000GT600D
Solder Mask SupplierTAIYO
Solder Mask ColourGreen
Number of Solder Masks2
Thickness of Solder Mask14um

Type of Silkscreen InkIJR-4000 MW300
Supplier of SilkscreenTaiyo
Color of SilkscreenWhite
Number of Silkscreen1

Mininum Trace (mil)5.8mil
Minimum Gap(mil)5.4mil

Surface FinishImmersion Gold
RoHS RequiredYes
Warpage 0.25%

Thermal Shock TestPass, 288±5ºC,10 seconds, 3 cycles.
No delamination, no blistering.
Solderablity TestPass, 255±5ºC,5 seconds Wetting Area Least 95%
Function 100% Pass electrical test
WorkmanshipCompliance with IPC-A-600H & IPC-6012C Class 2

Microsection Hole Wall (um)
Hole Wall Cu Thickness≥20 um Hole Wall Cu Roughness≤25.4 um
NO.ABCEAVE
126.854 25.654 23.386 25.026 24.306 23.936 24.442
224.344 23.144 23.204 24.204 24.844 24.124 23.754
325.249 24.049 24.109 25.029 24.029 24.659 21.263

Outline dimension  Unit: mm
NO.Required Dimension (toerance)Actual dimension
1210.72 ±0.15210.78 210.82 210.60 210.80
2212.42 ±0.15212.35 212.33 212.38 212.36

Drill Table (mm)
NO.Requerment Dimension (tolerance)PTH/NPT
10.450 ±0.076Y
20.600 ±0.076Y
30.800 ±0.076Y
40.900 ±0.076Y
50.950 ±0.076Y
61.000 ±0.076Y
71.250 ±0.076Y
81.300 ±0.076Y
91.400 ±0.076Y
101.600 ±0.076Y
111.700 ±0.076Y
122.000 ±0.076Y
132.550 ±0.076Y
143.000 ±0.076Y
153.250 ±0.076Y
163.500 ±0.05N

Learn PCB and Buy PCB --- HASL

Hot air solder leveling is for short HASL, which is a common type of surface finish used on printed
circuit boards (PCBs). We dipped the PCBs (with exposed copper surfaces) into a bath of molten
solder, then remove the excess solder on PCB surface and in the holes by strong hot air(which
we call it HASL machine) to get a glossy layer of coating.


One is alloy of tin and lead. The temperature of smelting furnace for Tin/Led is about 240ºC.
Another one is pure tin, because lead is harmful to human body, EU has forbidden using tin/lead.
So the popular is pure tin or HASL Lead free. The temperature of smelting furnace for pure tin is
highly at 300ºC, and plus the operating environment, high temperature and high etching are great
harm on PCB itself. Due to its hot air generated, HASL has low planarity. It makes this surface
finish unsuitable for use with fine pitch components. It has hidden danger of board warp or twist
under high thermal stress. To avoid this disadvantages, high Tg material and PPare took into
consideration for some PCB user. But it also has excellent wetting during component soldering
and it can avoid copper corrosion. So it is also mostly used in single sided PCB, Double sided
PCB and some multilayer PCB.
