8 Layer PCB Tacoinc Tly-5 PCB Circuit Board PCB Edge Plating

Name: 8 Layer PCB Tacoinc Tly-5 PCB Circuit Board PCB Edge Plating
Brand: all-electronics-online.com
SKU: 835442155
Availability: InStock
Rating: 4.5 (24 reviews)

Price:	US $ 1.01/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC-624-V6.24
Board Thick:	1.6mm
Surface Finish:	Immersion Gold
Out Layer Copper:	35 Um (1 Oz)
Inner Copper Thick:	35 Um (1 Oz)
Soldermask Color:	Green
Silkscreen Color:	White
Minimum / Maximum Holes:	0.35/3.5mm
Minimum Trace And Space:	4 Mil/4 Mil
Board Plating:	0.0029"
Test:	100% Electrical Test
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Flame Retardant Properties:	V0

Product Description

Company Profile
Bicheng Enterprise Limited which was founded in Shenzhen China in 2003 is a professional
PCB export enterprise. We have established a good relationship of cooperation with well-known
enterprises in the same industry. Our PCB products range from fiberglass PCB, high frequency
PCB to metal core PCB and ceramic PCB's. This is a unique printed circuit board supplier and
export enterprise. She has groups of skilled manufacturing facilities just like the experienced
football players in the football field and every batch of shipment is like a beautiful gift transmitted
to your hands.

Printed Circuit Board

Aluminum PCB

High Frequency PCB

Flex PCB

Technology Information

Design For Manufacture

Serial NO.	Procedure	Item	Manufacturing capability
			Large volume (S<100 m²)	Middle volume (S<10 m²)	Prototype (S<1m²)
			Large volume (S<100 m²)	Middle volume (S<10 m²)	Prototype (S<1m²)
35	Solder mask (18um, 35um, 70um etc are finished copper. If not mentioned copper, finished 1oz is the default value )	Maximum via-plug diameter	0.5mm	0.5mm	0.5mm
36		Min.width of solder mask bridge	Green:5mil (35um)	Green:4mil (35um)	Green:4mil (35um)
37			Yellow:5mil (35um)	Yellow:4mil (35um)	Yellow:4mil (35um)
38			Blue:5mil (35um)	Blue:4mil (35um)	Blue:4mil (35um)
39			Black:6mil (35um)	Black:6mil (35um)	Black:6mil (35um)
40			White:6mil (35um)	White:6mil (35um)	White:6mil (35um)
41			All of Matt: 6mil	All of Matt: 6mil	All of Matt: 6mil
42			Green:5mil (70um)	Green:4mil (70um)	Green:4mil (70um)
43			Yellow:5mil (70um)	Yellow:4mil (70um)	Yellow:4mil (70um)
44			Blue:5mil (70um)	Blue:4mil (70um)	Blue:4mil (70um)
45			Black:6mil (70um)	Black:6mil (70um)	Black:6mil (70um)
46			White:6mil (70um)	White:6mil (70um)	White:6mil (70um)
47		Open solder mask	4mil(35um)	4mil(35um)	3mil(35um)
48		Solder mask coverage	4mil(35um)	4mil(35um)	3mil(35um)
49		Min.width of solder mask text	9mil(35um)	9mil(35um)	8mil(35um)
50		Min.thickness of Solder mask	9um(35um)	9um(35um)	9um(35um)
51		Max.thickness of solder mask	30um(35um)	30um(35um)	30um(35um)
52	Silkscreen	Min.width of silkscreen text	6mil	6mil	5mil
53		Min.height of silkscreen text	35mil	35mil	30mil
54		Min.space from silkscreen to pads	6mil	6mil	5mil
55		Colour of silkscreen	White, Black, Yellow
56	Carbon ink	Carbon ink covers conductor or pads	14mil	13mil	12mil
57	Carbon ink	Mid distance from carbon ink to pads	12mil	11mil	10mil
58	Peelable mask	Peelable mask covers conductor or pads	8mil	7mil	6mil
59		Min.distance from peelable mask to pads	14mil	13mil	12mil
60		Max.via-plug of Silk-screen method	2.0mm	2.0mm	2.0mm
61		Max. via-plug of aluminum foil method	4.5mm	4.5mm	4.5mm
