90W 90mm AC Induction Gear Motor

Name: 90W 90mm AC Induction Gear Motor
Brand: all-electronics-online.com
SKU: 775231885
Availability: InStock
Rating: 5 (119 reviews)

Price:	US $ 34.98-80.88/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	GS5IK90GU
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Output Power:	90W
Voltage:	100/110/120/220/230V
Frequency:	50/60Hz
Rated Torque:	700mn.M
Rated Speed:	1250rpm
Phase:	1pH/3pH
Gearbox:	Can Be Provided
Number Of Stator:	Single-Phase
Function:	Control
Certification:	UL CE
Brand:	Greensky

Product Description

60mm~104mm, 6W~180W AC Induction Motor

Introduction

Generally, Micro Induction Motor refers to the motor rotated by the induction. Induction Motor relies on capacitor and electromagnetism when starting and rotating. Though its starting torque is not very high, it has a simple structure, high efficiency and can rotate continue.

Specifications

1. Dimensions of device: 90mm
2. Rated Power: 90W
3. Voltage: 100/120/220/230V
4. CCC, CE, UL, CU
5. Can be customized

SPECS/CONTINUOUS RATING

Model		Output power W	Voltage V	Frequency Hz	Current A	Starting Torque mN.m	Rated Torque mN.m	Rated Speed r/min	Capacitor μF
Lead Wire Type	Terminal Box Type
GS5IK90GU-AF	GS5IK90GU-AFT	90	1ph100	50	1.55	450	700	1250	25
				60	1.85		570	1550
GS5IK90GU-EF	GS5IK90GU-EFT	90	1ph110	60	1.4	500	570	1550	20
			1ph120		1.45
GS5IK90GU-CF	GS5IK90GU-CFT	90	1ph220	50	0.72	450	700	1250	5
			1ph230		0.7
GS5IK90GU-HF	GS5IK90GU-HFT	90	1ph220	60	0.71	450	570	1550
			1ph230		0.75
GS5IK90GU-SF	GS5IK90GU-SFT	90	3ph220	50	0.6	1350	700	1250	_
				60	0.55	1100	570	1550

Allowance Torque Unit: Upside (N.m)/ Belowside (kgf.cm)

TYPE Motor/Gearhead	Gear Ratio		3	3.6	5	6	7.5	9	12.5	15	18	25	30	36	50	60	75	90	100	120	150	180	200
	Speed r/min	50Hz	500	417	300	250	200	166	120	100	83	60	50	41	30	25	20	16	15	13	10	8.3	7.5
	Speed r/min	60Hz	600	500	360	300	240	200	144	120	100	72	60	50	36	30	24	20	18	15	12	10	9
GS5IK90GU-AF GS5IK90GU-EF GS5IK90GU-CF GS5IK90GU-HF GS5IK90GU-SF	5GUKB	50Hz	1.7	2	2.8	3.4	4.3	5.1	6.4	7.7	9.2	11.6	13.9	16.6	20	20	20	20	20	20	20	20	20
		50Hz	17	20	28.6	34.7	43.9	52	65.3	78.6	93.3	118	142	169	200	200	200	200	200	200	200	200	200
		60Hz	1.4	1.7	2.3	2.8	3.5	4.2	5.2	6.2	7.5	9.4	11.3	13.5	19	20	20	20	20	20	20	20	20
			14	17	23.5	28.6	35.7	42.9	53.1	63.3	76.5	95.9	115	138	19	200	200	200	200	200	200	200	200
			14	17	23.5	28.6	35.7	42.9	53.1	63.3	76.5	95.9	115	138	19	200	200	200	200	200	200	200	200

Greensky's advantage

On the site you can find a range of renewable products including ac/dc motor, ac induction motor, reversible motor, blake motor, speed motor, ac angel motor, gear motor, planetary gear box, worm gear box and their relevant components.

If you have any other questions, please feel free to contact us.
