| Prod Model: |
BIC-566-V5.66 |
| Final Foil External: |
2 Oz |
| Final Height Of PCB: |
0.8mm |
| Surface Finish: |
Immersion Gold |
| Solder Mask Color: |
None |
| Colour Of Component Legend: |
None |
| Mininum Trace (Mil): |
13 Mil |
| Minimum Gap(Mil): |
15 Mil |
| Minimum / Maximum Holes: |
0.3/3.21mm |
| Board Plating: |
0.0030" (0.076mm) |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Dielectric: |
RO4350b |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
Product Description
Company Profile
In the past year, Bicheng has served thousands of customers in the world in the applications of
power electronics, intercom systems, telecommunications etc. Bicheng now is one of the estab
-lished brands in PCB industry.
Our clients are from worldwide.
Australia: Perth, Melbourne, New South Wales, South Australia, West Australia
Austria: Breitenfurt bei Wien, Graz
Bangladesh: Purana Paltan
Belgium: Deinze, Hasselt
Bulgaria: Plovdiv
Brazil: Caxias do Sul
Canada: Quebec, Ontario, Vancouver
Czech: Pardubice, Horní Počernice
France: Villeneuve La Garenne Cedex, Montchenu
Germany: Stuttgart, Garbsen, Hamburg, Altenburg, Velbert Kleinmachnow, Potsdam
Hungary: Budapest
India: Tamilnadu
Ireland: Cork
Israel: Nettanya City, Ben-Gurion Airport, Tel Aviv, Yahud, Acre,
Italy: Peschiera Borromeo, Verona, Mezzocorona, Pietrasanta Lucca, Torino
Kuwait: Safat
Malta: Mosta
Malaysia: Selangor
Mexico: Leon Guanajuato
Portugal: Guimarães
South Korea: Gyeonggi-DO
Serbia: Kragujevac
Sweden: Göteborg , Siljansnäs,
Thailand: Bangkok, Chonburi
Turkey: Ankara, Istanbul, Kocaeli
The Netherlands: Diemen
UK: Bristol, Surrey
Ukraine: Kiev
USA: Connecticut, Alaska, New York City, Miami,, New Jersey, Texas, Colorado, Largo, California, Candler
Vietnam: HoChiMinh City
Zambia: Kitwe
High Frequency PCB
Flexible Printed Circuit
Metal Core PCB
PCB Board
Hybrid PCB stack up
4 layer PCB, RO4350B combined with FR-4 Core.
Genuine RO4350B 4 layer PCB vs FR-4 4 layer PCB
Build-up of FR-4 PCB (4 layer) Build-up of RO4350B PCB (4 layer)
Copper track --- Layer 1 Copper track --- Layer 1
Prepreg(PP) RO4350B Core
Copper track --- Layer 2 Copper track --- Layer 2
FR-4 Core Rogers Prepreg(PP)
Copper track --- Layer 3 Copper track --- Layer 3
Prepreg(PP) RO4350B Core
Copper track --- Layer 4 Copper track --- Layer 4Printed Circuit Board Capability
| Parameter | Value |
| Layer Counts | 1-32 |
| Substrate Material | FR-4(including High Tg 170, High CTI>600V);
Aluminum based; RO4350B, RO4003C;
Polyimide, 94HB and FR-1 (upon request) |
| Maximum Size | Flying test: 900*600mm,
Fixture test 460*380mm,
No test 1100*600mm |
| Board Outline Tolerance | ±0.0059" (0.15mm) |
| PCB Thickness | 0.0157" - 0.3937"
(0.40mm--10.00mm) |
| Thickness Tolerance(T≥0.8mm) | ±8% |
| Thickness Tolerance(t<0.8mm) | ±10% |
| Insulation Layer Thickness | 0.00295" - 0.1969"
(0.075mm--5.00mm) |
| Minimum Track | 0.003" (0.075mm) |
| Minimum Space | 0.003" (0.075mm) |
| Outer Copper Thickness | 35 µm--420 µm
(1 oz-12 oz) |
| Inner Copper Thickness | 17 µm--420 µm
(0.5 oz - 12 oz) |
| Drill Hole(Mechanical) | 0.0059" - 0.25"
(0.15mm--6.35mm) |
| Finished Hole(Mechanical) | 0.0039"-0.248"
(0.10mm--6.30mm) |
| DiameterTolerance(Mechanical) | 0.00295"
(0.075mm) |
| Registration (Mechanical) | 0.00197"
(0.05mm) |
| Aspect Ratio | 12:1 |
| Solder Mask Type | LPI |
| Min Soldermask Bridge | 0.00315"
(0.08mm) |
| Min Soldermask Clearance | 0.00197"
(0.05mm) |
| Plug via Diameter | 0.0098" - 0.0236"
(0.25mm--0.60mm) |
| Impedance Control Tolerance | ±10% |
| Surface Finish | HASL,HASL LF,ENIG,
Imm Tin,Imm Ag,
OSP, Gold Finger |
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
