Alumina Ceramic PCB Circuit Board with Fast Ceramic PCB Prototype

Name: Alumina Ceramic PCB Circuit Board with Fast Ceramic PCB Prototype
Brand: all-electronics-online.com
SKU: 684308362
Availability: InStock
Rating: 4.7 (90 reviews)

Price:	US $ 0.3-0.33/Piece
Trade Terms:	FOB
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	FL
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Board Material:	Ceramic
Board Thickness:	1.6 mm
Copper Thickness:	1 Oz (35um)
Surface Treatment:	HASL Lead Free
Type:	Rigid Circuit Board
Flame Retardant Properties:	V0
Dielectric:	FR-4
Material:	Aluminum
Brand:	Fastline
Base Material:	Ceramic

Product Description

Commodity Introduction
This is a type of Ceramic PCB for the application of IR Module. It's a 2 Layer board at 1.6mm thick.
The base laminate is from ITEQ, Solder mask and silkscreen from Taiyo. It's fabricated per IPC
6012 Class 2 using supplied Gerber data. Each 10 boards or panels are packed separately.

Parameters & Data Sheet

PCB SIZE	190 x 190mm=48PCS
BOARD TYPE
Number of Layers	Double sided PCB, 2 Layer PCB
Surface Mount Components	YES
Through Hole Components	no
LAYER STACKUP	copper ------- 35um(1oz)+plate TOP layer
	Ceramic 0.8mm
	copper ------- 35um(1oz)+plate BOT Layer
TECHNOLOGY
Minimum Trace and Space:	8mil/8mil
Minimum / Maximum Holes:	0.7/2.1mm
Number of Different Holes:	3
Number of Drill Holes:	653
Number of Milled Slots:	84
Number of Internal Cutouts:	0
Impedance Control	no
BOARD MATERIAL
Glass Epoxy:	FR-4, ITEQ IT-180 TG>170, er<5.4
Final foil external:	1.5oz
Final foil internal:	0oz
Final height of PCB:	1.6mm ±0.16
PLATING AND COATING
Surface Finish	Immersion Gold (15.3%) 2micoinch over 100 microinch nickel
Solder Mask Apply To:	Top and Bottom, 12micron Minimum
Solder Mask Color:	Gloss Green, Taiyo PSR-2000GT600D
Solder Mask Type:	LPSM
CONTOUR/CUTTING	Routing, Fiducial Marks
MARKING
Side of Component Legend	TOP
Colour of Component Legend	White, IJR-4000 MW300, Taiyo Supplied.
Manufacturer Name or Logo:	Marked on the board in a conductor and leged FREE AREA
VIA	Plated Through Hole(PTH), via tented
FLAMIBILITY RATING	UL 94-V0 Approval MIN.
DIMENSION TOLERANCE
Outline dimension:	0.0059"
Board plating:	0.0029"
Drill tolerance:	0.002"
TEST	100% Electrical Test prior shipment
APPLICATION:	IR module, Wireless Speakers Tv Antenna Gps Tracker Cctv Usb Hub
TYPE OF ARTWORK TO BE SUPPLIED	email file, Gerber RS-274-X, PCBDOC etc
SERVICE AREA	Worldwide, Globally.
