ANSI Standard PVC Insulated and Sheathed K Type Thermocouple Compensation Wire

Name: ANSI Standard PVC Insulated and Sheathed K Type Thermocouple Compensation Wire
Brand: all-electronics-online.com
SKU: 803941085
Availability: InStock
Rating: 4.9 (139 reviews)

Price:	US $ 0.59-1.5/Meter
Min Order:	100/Meter
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	H-TP-1110
Type:	Insulated
Conductor Type:	Solid
Insulation Material:	PVC
Certification:	ANSI
Application:	Thermocouple Wires
Conductor Material:	Chromel and Alumel
Sheath Material:	PTFE / PVC / PFA
Range Of Application:	Machinery,Thermocouple,Electricity
Brand:	Ohmalloy

Product Description

ANSI standard PVC Insulated and Sheathed K Type Thermocouple compensation Wire

Item No.	K-VS-VS-1.29
Conductor Material	+Chromel, -Alumel
Conductor Dia	1.29mmX2
Insulation material	Vitreous Silica
Insulation color	+white, -white
Cable Construction	Parallel
Inner Shielding material	/
Jacket material	Vitreous Silica
Jacket color	White
Outer Shielding Material	/
Insulated DIA	1.0mm
Cable DIA	3.7mm*5.2mm
Cable Dielectric Test	DC.500v
Net weight	40kg/km

Chromel (KP) is an alloy made of approximately 90 percent nickel and 10 percent chromium that is used to make the positive conductors of ANSI Type E (chromel-constantan) and K (chromel-alumel) thermocouples. It can be used up to 1100 °C in oxidizing atmospheres.

(Common Name: KP, NiCr10, NiCr90/10, Thermothal P )

Normal composition%

Nickel	90	Manganese	0
Chromium	10

CHARACTERISTICS:
Temperature coefficient	0.00032 K⁻¹
Electrical resistivity	0.706 µΩ m
Mechanical properties
Elongation at break	<44%
Izod impact strength	108 J m⁻¹
Modulus of elasticity	186 GPa
Tensile strength	620-780 MPa
Physical properties
Density	8.5 g cm⁻³
Melting point	1420 °C
Thermal properties
Coefficient of thermal expansion	12.8×10⁻⁶ K⁻¹ at 20-1000 °C
Maximum use temperature in air	1100 °C
Thermal conductivity	19 W m⁻¹ K⁻¹ at 23 °C

Style of supply

Alloys Name	Type	Dimension
Chromel-W	Wire	D=0.05mm~12mm
Chromel-R	Ribbon	W=0.5-10m	T=0.05~1.5mm
Chromel-S	Strip	W=10~150mm	T=0.1~3.0
Chromel-B	Bar	Dia=5-12mm	L=50~1500

Ohmalloy Material Co., Ltd is a high-tech enterprise which specialized in making all kinds of alloy such as high resistance alloy, low-resistance copper nickel alloy, precision alloy, FeCrAl alloy and thermocouple Alloy.

Ohmalloy Material Co., Ltd have a full production line from melting, surface cleaning, rolling and slitting, full set of testing machine and can meet all kinds of technical requirement from customer. Our product is widely used in heating equipment, big steel mill, mineral, electrical equipment, food machinery, auto industry, aerospace industry. Our product not only is popular in domestic market, but also been exported to all over the world.

Our company aims to be the best-quality alloy producer in the world. We insist on developing the more advanced alloy strip technology, to serve all the customer, improve people's living level, make a more green earth in the future.

Our company supplies different kinds of products. With high quality and reasonable price. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
