Automatic Switch Ceiling Mounted PIR Motion Sensor for Light

Name: Automatic Switch Ceiling Mounted PIR Motion Sensor for Light
Brand: all-electronics-online.com
SKU: 826800025
Availability: InStock
Rating: 4.7 (137 reviews)

Price:	US $ 4-4.5/Piece
Min Order:	1/Piece
Pay Type:	L/C,T/T,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	WL-KG-3A
Brand Name:	Wale
Place Of Origin:	Guangdong, China(Mainland)
Certificated:	Ce and RoHS
Warranty:	3 Years
Type:	Sensor
Installation Mode:	Ceiling Mounted
Application:	Home, Industry
Function Type:	Motion Detector
Detection Type:	PIR

Product Description

Wired Ceiling PIR Motion Sensor Switch for Light

Technical Specification

Model	KG-1B
Power source	220V/AC-240V/AC, 100V/AC-130V/AC optional
Power Frequency	50-60Hz
Rated Load	800W(100~130V/AC) 1200W(220~240V/AC) 1500W(100~130V/AC) 3000W(220~240V/AC)
Working Voltage	DC9-16V
Working Current	15mA
Detection Angle	360°
Detection Distance	15m
Installation height	1.5-3.5m
Installation mode	Ceiling mounted
Time Delay	5Sec.~9Min.
Detection Motion Speed	0.6-1.5m/s
Anti RF interference	30V/m 10MHz-1GHz
Anti-white light interference	>900LUX
Alarm output	NC , 100mA/DC12V max
Temper output	NC , 100mA/DC12V max
Operating Temperature	-10ºC~ +55ºC
Relative Humidity	≤95% (non-condensing)
Unit size	Φ135*24mm

FAQ

Q1: Where is your Factory? How can I visit your company?
A1: Our factory is located in Shenzhen, Guangdong, China. We could pick you up from the hotel you live when you come to Shenzhen.

Q2:  Warranty?
A2:  Normally it's one year, but it will be 2 years if you can be our agent

Q3: Can I get some Samples? Are your samples free or need cost?
A3: It can be free, but anyway we have to charge for the samples first, the sample charge can be returned after official order placed.

Q4: Could you please make OEM for us?
A4: Surely yes.OEM&ODM, any your customized alarm system we can help you to design and put into product

Q5: How long can I get your samples?
A5: For samples, it will be ready for delivery in 3-7 days after payment. The samples will be sent to you by express.

Q6: When can I get the price?
A6: Your inquiry related to our products or prices will be replied in 24 hours. If you are very urgent to get the price, please call us by 86-17875047736.

Q7: What's your Payment method supported?
A7: We accept T/T, Western Union, L/C etc.

Q8: Shipping & Express
A8: 1). If you have specified shipping agent, we will contact them and to deliver your goods.
       2) If you do not have specified shipping agent, we will delegate a credible one for you to deliver your goods. Goods could be delivered by air, by sea, by express (DHL, UPS, TNT or FEDEX).

Established in Shenzhen on July 25, 2006, Shenzhen Wale Group Co., Ltd is a national high-tech enterprise mainly on researching, developing and manufacturing high-tech products for security GSM home alarm, terrorism and violence, quantum detection, and energy environment, as well as a solution provider about industry data analyzing

The factory and office are located in Shenzhen, which is near to ports for sea delliver. The factory can support OEM/ODM service for long term cooperation. Our products are welcomed by our forg

Every year, we will going to attend Security Exhibition all over the world, such as USA, Russia, Essen, India, Dubai, etc.

We guaranteed products at a competitive price and high quality. At present, our products have a very good sale in domestic and overseas market. We wish to cooperate with you to create a bright future and mutual benefit. Much appreciation for your prompt attention in advance, we are eager to look forward to hearing from you soon.
