| Prod Model: |
JKTSC |
| Name: |
PV1f Solar PV Cable; Photovotaic Cable |
| Rated Voltage: |
AC 600/1000V, DC 1000/1800V |
| Test Voltage: |
6500V, 50Hz, 5min |
| Approvals: |
TUV 2pfg 1169/08.2007 PV1-F |
| Fire-Resistance Performance: |
IEC 60332-1 |
| Smoke Emission: |
IEC 61034; En 50268-2 |
| Low Fire Load: |
DIN 51900 |
| Application Standards: |
Une 211 23; Une 20.460-5-52, Ute C 32-502 |
| Temperature: |
Environment +90degree, Cable 120degree |
| Color: |
Black, Red, Blue or as Per Customer's Request. |
| Application: |
Solar Power System |
| Voltage: |
Low and Medium Voltage Cable |
| Current: |
DC & AC |
| Insulation Material: |
XLPE |
| Certification: |
PSE, TUV, UL, En50618 |
| Sheath Material: |
XLPE |
| Wire Core Material: |
Tinned Copper |
| Model: |
PV1-F |
| Brand: |
Jiukai/OEM |
Product Description
Bottom price top sell 4mm2 single core solar cableProduct Description
Especially for the connection between Solar power generation device connector and connection of inverter, under the condition of different climate outdoor installation, and can adapt to the dry and wet indoor working environment.
High heat-resistant flame retardant, flame retardant from ectinguish comply with IEC60332-1-2+EN60332-1-2.
Halogen-free,Not contain hydrochloric acid comply with EN50627-2-1
Not contain fluorine comply with EN60684-2
Climate resistance
Construction | Conductor Construction | Conductor ø | Outer ø | Resistance Max. | Current Carring Capacity |
n×mm² | n/m | mm | mm | Ω/Km | A |
1×1.5 | 30/0.25 | 1.58 | 4.9 | 13.3 | 30 |
1×2.5 | 50/0.25 | 2.02 | 5.45 | 7.98 | 41 |
1×4.0 | 56/0.3 | 2.30 | 6.1 | 4.75 | 55 |
1×6.0 | 84/0.30 | 3.42 | 7.2 | 3.39 | 70 |
1×10.0 | 142/0.30 | 4.56 | 9 | 1.95 | 98 |
1×16.0 | 228/0.30 | 5.60 | 10.2 | 1.24 | 132 |
1×25.0 | 361/0.30 | 6.95 | 12 | 0.795 | 176 |
1×35.0 | 525/0.30 | 8.74 | 13.8 | 0.565 | 218 |
1×50.0 | 720/0.30 | 9.20 | 14.8 | 0.393 | 280 |
1×70.0 | 988/0.30 | 11.00 | 16.9 | 0.277 | 350 |
1×95.0 | 1349/0.30 | 12.50 | 18.7 | 0.21 | 410 |
1×120 | 1691/0.30 | 14.20 | 20.7 | 0.164 | 480 |
Conductor | Tinned Copper,according to VDE0295/IEC60228,Class5 |
Insulation | Electron-beam cross-linked Polyolefin Copolymer TUV 2PfG/1169 |
Sheath | Electron-beam cross-linked Polyolefin Copolymer TUV 2PfG/1169 |
Nominal Voltage | AC 600/1000V DC 1000/1800V |
Characteristic | Heat-resistant flame retardant,UV/ozone/hydrolysis/climate resistance |
Sheath Color | Black or as per customer's requeit |
Temperature Rating | 45°c upto +125°c -40°F upto +257°F |
Ambient temperature | 25years(TUV) -40°c upto +90°c -40°F upto +194°F |
Max.Short circuit temperature | 280°c,+536°F |
Bending Radius | Fixed installation>4X Occasionally moved>5X |
Applications | Especially for the connection between Solar power generation device connector and connection of inverter,Under the condition of different climate outdoor installation,and can adapt to the dry and wet indoor working environment |
Packaging & ShippingHS CODE | 8544492100 |
Packaging Details | 1. Hollow/Plastic/Wooden Drum: 100M/Drum,500M/Drum,1000M/Drum. |
2. According to customer requirement. |
Delivery Detai | 1: 5-10days if the goods are in stock |
2: 15-20 days if the goods are not in stock, it is according to quantity. |
3: This is a matter of negotiation. |
Certification
| ISO9001:2008 | No:082737 |
| TUV | No: R50203088 |
| UL | No: E480012 |
Company Information
Shanghai Jiukai Wire & Cable Co., Ltd
Our company is a national high and new tech enterprise. We consistently dedicate to the R&D, production and sales of wires and cables. We are professional HV&LV power cables, LV electrical wires and security cables in China. We introduce the most advanced automatic production lines, first-class testing & inspection equipments and laboratory for cable security test and application test. We have the technical team of local & overseas experts in cable industry. Strict quality control and safety policy ensures our products meet and exceed the GB industry standards. Our Cables are well sold to Americas, Europe, Middle-east, Southeast Asia and Africa. We establish the strategic partnership with many global electronic enterprises. We mainly produce nearly 10 categories (thousands of kinds) cables, such as audio & video cable, elevator cable, data cables, computer cable, CAT5E LAN cable , CAT 6 LAN cable, solar PV cable, UL wire, flexible cable and special cable. All our cables has already got the certificates of national or international professional testing organizations,such as China CCC certificate , US UL certificate , European Union CE Certificate , German TUV, Quality system certification certificate ISO9001:2000.
Why Choose UsWe are a professional wire and cable manufacturer
1.Jiukai sends all the items with Outgoing Quality Inspection Report;
2.The copy of TUV certification will be sent along with the products;
3.We guarantee100% good quality when the products are sent out of factory;
4.We ship the goods by the fastest way of EMS,UPS,DHL and TNT,reaching most countries within 7 days;
5.Jiukai is ship to world wide;
6.Once we shipped the products,our after-sale service will send you the tracking number;
7.If your item is not as described or faulty when you receive it, we will send replace it for you with no additional charge;
8.If the item is found non-defective,the item will be sent back to the buyer at buyer's expense.
FAQQ: Are you trading company or manufacturer ?
A: We are factory.
Q:How long solar cable can be loaded in one 20" container?
A:Can load:1×4mm² solar cable 250km; 1×6mm² solar cable 200km;1×10mm² solar cable 120km;1×16mm² solar cable 80km;2×4mm² solar cable 128km;2×6mm² solar cable 80km.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shipment.
