BT Drop Wire for Communication 1X2X1.0mm (0.8mm2)

Prod Model:	BVVB
Color:	Black
Type:	Insulated
Conductor Type:	Solid
Application:	Overhead
Conductor Material:	Copper
Certification:	CCC
Insulation Material:	LDPE
Range Of Application:	Communication
Brand:	Yifang

Product Description

BT Drop Wire for communication 1X2X1.0mm (0.8mm2)
Drop Cable 1x2x1.0mm
Specifications:
1 pair ; 2 conductors ; both with 1.0mmdiameter
Black color LDPE (Low Density Polyethylene)
(0.910-0.925 g/cm3) conductors covered
Conductor Insulation thickness 0.64mm
Black color Pvc exterior covered protect againstUV rays
Minimum exterior cover thickness 1.15mm
Exterior cover Dimensions 4.9 x 7.75
Tolerance diameter 0.02% ;18 Awg caliber
Conductor Electrical resistance at 20 ºC: 22Ohm/Km.
Maximum mutual capacity 100 nF/Km.
Operatival temperature > 75 ºC
High voltage test (Vcc-1min): 1500 Vcc-1 min
Minimum insulation resistance at 20 ºC: 300MO - Km.
Cable weight : 53,10 kg/km

Conductor material	Copper wire
Cores No	2
Insulation	LDPE
Sheath	PVC
shape	Flat

In a communications network, a drop is the portion of a device directly connected to the internal station facilities, such as toward atelephone switchboard, toward a switching center, or toward a telephone exchange. A drop can also be a wire or cable from a pole or cable terminus to a building, in which case it may be referred to as a downlead. These cables may be reinforced to withstand the tension (due to gravity and weather) of an aerial drop (i.e., hanging in air),
