Cable for Solar Panel Connection with Diameter of 4 M2

Cable for Solar Panel Connection with Diameter of 4 M2
Price: US $ 0.63-0.7/Meter
Trade Terms: FOB,CFR,CIF
Min Order: 100/Meter
Pay Type: L/C,T/T,Western Union
Prod Model: FCY-010
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Diameter: 4mm2
Voltage: 1000V
Current: 30A
Warranty: 25 Years
Weight: 25kg/500m
OEM: Available
Type: Insulated
Conductor Type: Solid
Application: Overhead
Conductor Material: Copper
Insulation Material: Rubber
Certification: VDE
Brand: Fg

Product Description

TUV & UL Approval   Conductor: Stranded tinnet copper
Insulation: halogen free crosslinked polyolefin
sheath: halogen free crosslinked polyolefin
Nominal Cross-Section: 4mm2
Rated temperature: -40~+90ºC
Rated Voltage: DC:1.8kv --AC:0.6/1kv
finished cable O.D. :6.2±0.1mm conductor resistance(20ºC):≤5.09Ω/km
Rated Current: 25~32A
Weathering Resistance: UV
Burning Behaviour: (IEC60332-1,UL1581 VW-1)
No of core:1                   No of core:1



Wire: Class 5,tinned

UV resistant

Insulation material: XLPE

Hign wear and abrasion resistance

Double insulated

Flame test according to :DIN EN 50265-2-1 UL1571(VW-1)

Halogen-free

Smallest permissible Bending Radius : 5 x D

High resistance against oil,greases,oxygen and ozone

Temperature range: -40~+90 degree

Micode-resistant

Colours: Black,Red

Flagsun has been global supplier of renewable energy solutions since 2008, mainly offer Solar system, Solar panel, PV inverter, controller, Solar light & application products, cable etc...With advanced production equipment and strict quality control, we commit to offer reliable products at competitive cost, meanwhile we keep on designing and developing solar power solution ahead of customer' S needs. Through continuous innovation, we try to reduce manufacturing costs of solar electricity and improve solar energy technology to provide more green power for the world. Currently all of our products have been certified by CE, TUV, MCS, CEC and ISO9001, ensuring customer to use our products without any worry.

Flagsun is seeking every chance to have a long term partnership and cooperation as well as collaborative development with our suppliers and customers. Driven by our competence in solar energy, the delivery from anywhere to any place in the world, we are willing to take responsibility for the green planet, promote harmonious development for humanity, society and nature.

Flagsun sincerely invite you to create new energy for next generation, build a green home for our mankind forever.
