Prod Model: |
cbb61 |
Connect: |
Cable |
Current: |
a.C Single-Phase |
Certificated: |
Ce/TUV/RoHS/Reach |
Capacitance Tole: |
5% |
Type: |
Polypropylene Capacitor |
Application: |
Fan |
Package Type: |
Through Hole |
Capacitance: |
2.5UF |
Product Description
1. General description:
Broadly applied to running of single-phase AC motors at 0Hz(60Hz)frequency for washers and high efficiency compressors of refrigerators etc.
2. features:
The capacitor takes heavy-edge metallized, AI/Zn pp film or web-like fuse metallized PP film as dielectric, its components are assembled in flame-retardant ABS or PBT cylindrical crust, impregnated with flame-retardant epoxy resin, It has high reliability and
stability.
3.Technical parameter
Standard:GB3667-1997,same as IEC60252:193
Climate type:40/70/21, 40/85/21
Capacitance tolerance: ±5%
Dielectric dissipation factor: tg&≤0.002(50Hz~100Hz)
Life expectancy:3000h(Class C)or10000h(Class B)
CBB61 fan capacitor broadly applied to starting and running of AC single-phase motors at 50Hz(60Hz) frequency for air conditioners' fans,electric fans and exhaust fans etc.at comparatively low rated power. Specifications | Model No. | CBB61 Capacitor | Type | Polypropylene Fan Capacitor | Capacitance | 1~30uF | Structure | Single Film Capacitor | Manufacturing Material | Polypropylene | Electrolyte | Polypropylene Film | Rated Voltage | 200~500VAC | Operating Temperature | 40/70/21 or 40/85/21 | Capacitance Tolerance | ±5% | Class of Operation | Class B,Class C | Class of Safety Protection | P0/P2 | Package Type | Export Carton for CBB61 Fan Capacitor | MOQ | 1000 pcs | Size | Available on Request (Customized Fan Capacitor) |
Technical Specifications:Reference standards | GB/T 3667.1997 ( IEC60252-1993) | Climatic category | 40/70/21,40/85/21 | Class of operation | Class B(10000h) Class C(3000h) | Dissipation factor | 20×10-4(100Hz,20ºC) | Test voltage terminal to terminal UTT | 2 Un for 2 seconds | Test voltage terminal to case UTC | (2Un+1000)VAC or 2000VAC-50Hz for 60 seconds |
Service condition:
Altitude:≤2,000m Residual voltage in application:Less than 10% of rated voltage Allowed maximum voltage:Less than 1.1 time of rated voltage Permissible maximum current:Less than 1.3 times of rated current
Factory:

*Please note all the price are negotiable upon specifications, if you have any inquiry, welcome to contact us.
| |
| |
| |
| |
| |
| |
| |
| |
| |
4.Service condition
Altitude:≤2000m
Residual voltage in application:Less than 10% of rated voltage
Allowed maximum voltage: Less than 1.1 times of rated voltage
Permissible maximum current: Less than 1.3 times of rated current
Outline size
1.0UF/450VAC | 30*57 |
1.5UF/450VAC | 30*57 |
2.5UF/450VAC | 30*57 |
3.0UF/450VAC | 30*57 |
3.5UF/450VAC | 30*57 |
4.5UF/450VAC | 30*57 |
6.0UF/450VAC | 30*57 |
6.3UF/450VAC | 35*66 |
8.0UF/450VAC | 35*66 |
10.0UF/450VAC | 35*66 |
12UF/450VAC | 40*71 |
14UF/450VAC | 40*71 |
16UF/450VAC | 40*71 |
18UF/450VAC | 40*71 |
20UF/450VAC | 40*95 |
25UF/450VAC | 40*95 |
30UF/450VAC | 45*95 |
40UF/450VAC | 50*107 |
50UF/450VAC | 50*107 |
60UF/450VAC | 50*117 |
2UF/450V+CABLE | 30*59 |
4UF/450V + CABLE | 30*59 |
8UF/450V+CABLE | 35*69 |
10UF/450V+CABLE | 35*69 |
12UF/450V+CABLE | 40*73 |
16UF/450V+CABLE | 40*73 |
20UF/450v+cable | 40*98 |
25UF/450V+CABLE | 40*98 |
30UF/450V+CABLE | 45*98 |
40UF/450V+CABLE | 50*109 |
50UF/450V+CABLE | 50*109 |
60UF/450V+CABLE | 50*119 |
Service condition:
Altitude:≤2,000m
Residual voltage in application:Less than 10% of rated voltage
Allowed maximum voltage:Less than 1.1 time of rated voltage
Permissible maximum current:Less than 1.3 times of rated current
Factory:
*Please note all the price are negotiable upon specifications, if you have any inquiry, welcome to contact us.
HOMOR(hemao) in Chinese means Gracious & Exploration, which is the spirit we are following since our establish. For years we have been concentrating on offering the integrated power solution to our worldwide customers, and have gained good reputation in the market.
HOMOR specialize in manufacturing high quality power capacitor like BSMJ/BKMJ power capacitor, CBB60 motor running capacitor, CBB65 motor running capacitor, . To improve our research and high technology ability, we cooperated with China Electronics Technology Group which was Located in Beijing in 2011, now we have established PCB & electronic research center and advanced testing lab.
HOMOR is growing fast through year's great effort, . We are working with reliable distributors with online & offline network throughout China. We look forward to expanding our business with new agent and customer for our mutual benefit with each other.
Our company supplies different kinds of products. High quality and favorable price. We're pleased to get your Inquiry and we will come back to as soon as possible. We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with good quality at the reasonable price.
In strict accordance with GB/T12747-2004, IEC60831-1: 1996 Standard, its main products have gained the CE, CQC, CCC, UL certificate. Our capacitor has sales branches and distributors throughout China, and exports to more than ten countries including the United States, Canada, Brazil, Argentina, Russia, Bangladesh, South Korea, Malaysia and Singapore. Our capacitors are well-received by overseas users and has gained both economic and social benefits.
