China 1-1/4" Feeder Cable
| Price: |
US $ 1-2.5/Meter |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1000/Meter |
| Pay Type: |
L/C,T/T,D/P,Paypal,Western Union |
| Prod Model: |
1-1/4" Feeder Cable |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Number Of Conductors: |
1 |
| Color: |
Black |
| Jacket: |
Polyethylene |
| Name: |
1-1/4" Feeder Cable |
| Service: |
OEM/ODM |
| Sheath: |
Foamed PE |
| Tube: |
Annular Corrugated Copper |
| Application: |
Mobile Communication |
| Cover Material: |
PE |
| Certification: |
RoHS |
| Model: |
1-5/8 Aluminum Feeder Cable |
| Brand: |
Daytai |
Product Description
China 1-1/4" Feeder Cable
1-1/4" Feeder Cable Costruction:
1-1/4" Feeder Cable ,Copper tube+FoamedPE+Annular corrugated copper tube+Polyethylene Jacket.
1-1/4" Feeder Cable Specification:
1.Application:Used for all kinds of mobile communication; suitable for GSM,CDMA,PHS,TD-SCDMA,CDMA2000 and WCDMA etc...
2.Conductor Material:Copper
3.Sheath Material:Foam PE
4.Tube:Annular corrugated copper
5.Jacket:Polyethylene
6.Color:Black
7.Packing:500m/wood spool
8. CE,UL,ROHS standard
9.MOQ:20 km
10. OEM service
11.Sample is available
1-1/4" Feeder Cable Application:
1.Used for all kinds of mobile communication.
2.Suitable for :GSM,CDMA ,PHS ,TD-SCDMA ,CDMA2000 and WCDMA etc…
1-1/4" Feeder Cable Mechanical Characteristics
| Item | Specification | Remarks |
| Dynamic minimum bending radius | 380 mm | Repeated 15 times |
| Static minimum bending radius | 200 mm | Single bend |
| Tensile strength | 2000N | |
| Cable weight | 1100kg/km | |
1-1/4" Feeder Cable Electrical Characteristics
| Item | Specification |
| Characteristic impedance | 50±1Ω |
| Velocity | 88% |
| Minimum Insulation resistance | 5000 MΩ.km (DC 500V 1 minute) |
| Capacitance | 76 pF/m |
| Dielectric strength | 10000V (DC continued 1 minute ) |
| Peak power rating | 205kW |
| RF peak voltage | 4300 V |
| VSWR typical value | 1.15 (10M~3000MHz) |
| 1.10 (800M~1000MHz) |
| 1.10 (1700M~2000MHz) |
| 1.10 (2100M~2400MHz) |
