Hangzhou DAYTAI Network Technologies Co., Ltd. >> China Factory Price 1/2'' Super Flex Feeder Cable

China Factory Price 1/2'' Super Flex Feeder Cable

China Factory Price 1/2'' Super Flex Feeder Cable
Price: US $ 1-2.5/Meter
Trade Terms: FOB,CFR,CIF
Min Order: 1000/Meter
Pay Type: L/C,T/T,D/P,Paypal,Western Union
Prod Model: 1/2'' Super Flex Feeder Cable
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Number Of Conductors: 1
Color: Black
Jacket: PE
Name: 1/2" S Feeder Cable
Service: OEM/ODM
Application: Mobile Communication
Cover Material: PE
Certification: RoHS
Model: 1/2" S Feeder Cable
Brand: Daytai

Product Description

Factory Price 1/2'' Super Flex Feeder Cable

1/2 S Feeder Cable Description

1.1/2"S Radio Frequency Coaxial Cable
2.Copper clad Aluminum+Foamed PE+ Helical corrugated copper tube/Annular corrugated copper tube+Polyethylene Jacket.

1/2 S Feeder Cable Applications

1.Used for all kinds of mobile communication.
2.Suitable for :GSM,CDMA ,PHS ,TD-SCDMA ,CDMA2000 and WCDMA etc…

1/2 S Feeder Cable Mechanical characteristics

ItemSpecificationRemarks
Dynamic minimum bending radius120 mmRepeated 15 times
Static minimum bending radius70 mmSingle bend
Tensile strength1200N
Cable weight250kg/km

Electrical Characteristics of1/2"S Feeder Cable
ItemSpecification
Characteristic impedance50±1Ω
Velocity88%
Minimum Insulation resistance5000 MΩ.km (DC 500V 1 minute)
Capacitance76 pF/m
Dielectric strength4000V (DC continued 1 minute )
Peak power rating40kW
RF peak voltage1800 V
VSWR typical value1.15 (10M~3000MHz)
1.08 (800M~1000MHz)
1.08 (1700M~2000MHz)
1.08 (2100M~2400MHz)
