Circuit Board PCB Taconic Tsm-Ds3 0.13mm (5mil) Immersion Gold PCB

Name: Circuit Board PCB Taconic Tsm-Ds3 0.13mm (5mil) Immersion Gold PCB
Brand: all-electronics-online.com
SKU: 831532105
Availability: InStock
Rating: 4.8 (106 reviews)

Price:	US $ 2.46/Piece
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BIC-473.1757-V1.1
Final Foil External:	1oz
Final Height Of PCB:	1.6mm ±0.16
Surface Finish:	Immersion Gold
Solder Mask Color:	Green
Outline Dimension:	0.0059" (0.15mm)
Board Plating:	0.0030" (0.076mm)
Drill Tolerance:	0.002" (0.05mm)
Test:	100% Electrical Test Prior Shipment
Number Of Different Holes:	9
Glass Epoxy:	Fr-4, Iteq It-140, Tg>135, Er<5.4
Type:	Rigid Circuit Board
Dielectric:	FR-4
Material:	Fiberglass Epoxy
Flame Retardant Properties:	V0
Brand:	Bicheng

Product Description

Company Profile
Bicheng Enterprise Limited serves global clients from Shenzhen, China since 2003.
Variety of PCB technology to meet the market demands
HDI board
Heavy copper board
Hybrid material board
Blind via board
High frequency board
Metal core board
Immersion gold board
Multilayer board
Backplane board
Gold finger board

PCB Board

Aluminum PCB

Microwave PCB

Flexible PCB

PCB Capabilities (Bicheng Enterprise Limited 2017)
Layer Counts: 1-32
Substrate Material: FR-4(including High Tg 170, High CTI>600V); Aluminum based; RO4350B, RO4003C; Polyimide, 94HB and FR-1 (upon request)
Maximum Size: Flying test: 900*600mm, Fixture test 460*380mm, No test 1100*600mm
Board Outline Tolerance: ±0.0059" (0.15mm)
PCB Thickness: 0.0157" - 0.3937" (0.40mm--10.00mm)
Thickness Tolerance(T≥0.8mm): ±8%
Thickness Tolerance(t<0.8mm): ±10%
Insulation Layer Thickness: 0.00295" - 0.1969" (0.075mm--5.00mm)
Minimum Track: 0.003" (0.075mm)
Minimum Space: 0.003" (0.075mm)
Outer Copper Thickness: 35µm--420µm (1oz-12oz)
Inner Copper Thickness: 17µm--420µm (0.5oz - 12oz)
Drill Hole (Mechanical): 0.0059" - 0.25" (0.15mm--6.35mm)
Finished Hole (Mechanical): 0.0039"-0.248" (0.10mm--6.30mm)
Diameter Tolerance (Mechanical): 0.00295" (0.075mm)
Registration (Mechanical): 0.00197" (0.05mm)
Aspect Ratio: 12:1
Solder Mask Type: LPI
Min Solder mask Bridge: 0.00315" (0.08mm)
Min Solder mask Clearance: 0.00197" (0.05mm)
Plug via Diameter: 0.0098" - 0.0236" (0.25mm--0.60mm)
Impedance Control Tolerance: ±10%
Surface Finish: HASL, HASL LF, ENIG, Immersion Tin, Immersion Silver, OSP, Gold Finger

Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.

The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.

Different plant scale to suit for your requirements

16000 square meter factory building

30000 square meter month capability

8000 types of PCB per month

ISO9001, ISO14001, TS16949, UL Certified

We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.

A) Various kinds of PCB products

Double sided PCB

Multilayer PCB up to 32 layers

FR-4 PCB (Tg130, Tg170)

High frequency PCB (RO4350B, RO4003C)

Aluminum PCB (1W/MK, 2W/MK, 3W/MK)

Flexible PCB

HDI PCB Board

B) Multiple PCB technology to meet the market demands

Blind via PCB, Via in pad PCB, Fine pitch BGA PCB

Impedance controlled PCB

Heavy copper PCB

Hybrid material PCB

C) Many discount policies for new customers

SMT stencil foil, free of charge

Prototype shipping cost, free of charge

Prototype test, free of charge

PCB panelization, free of charge

D) High quality PCB services

Engineering design prevents problems from occurring in pre-production.

Meet your PCB needs from prototype to mass volume production.

Eligible products rate of first production: >95%

Delivery on time: >98%, door to door shipment service

Customer complaint rate: <1%

Choose BichengPCB means you choose hassle free.
