Cl21X Metallized Polyester Film Capacitor

Name: Cl21X Metallized Polyester Film Capacitor
Brand: all-electronics-online.com
SKU: 782111915
Availability: InStock
Rating: 4.8 (118 reviews)

Price:	US $ 0.31-0.58/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1000/Piece
Pay Type:	L/C,T/T,Paypal,Western Union

Contact Supplier

Showroom Product Company Profile

Prod Model:	CL21X
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type:	Polypropylene Capacitor
Application:	Automobile
Package Type:	Through Hole
Capacitance:	0.0015UF-1.0UF
Electrolyte:	Metalliezed Polypropylene Film
Usage:	AC / Motor, Power, Lighting, Air Conditioner, High

Product Description

CL21X Metallized polyester film capacitor

Metallized polypropylene film winding, non-inductive structure, epoxy resin encapsulated ,CP wire unidirectional terminations, low loss at high frequency, excellent insulation properties, small inherent temperature rise, capacitance stablity, good self-healing properties,.
Suitable for DC, high frequency, high current circuits, widely used in display equipment, audio equipment, audio-visual equipment, communications equipment, data processing and other various kinds of electronics equipment.

Reference standard	GB10190(IEC60384-2)
The rated temperature	85c
Climate type	55/100/21
The rated voltage	100V/160V,250V,400V,630V
Capacitance range	0.001uF~10uF
Capacitance of deviation	±5%(J),±10%(K),±20%(M)
Withstand voltage	1.6UR(5S)
Loss tangent	≤1.0%.(20ºC,1KHz)
Insulation resistance	≥50000MΩ,CR≤0.33uF(20ºC,100V,1min) ≥5000S,CR>0.33uF

Zhejiang Huaxi Electronics Co., Ltd is located at the foot of national key place of interest Yandang Mountain and abuts on "China Electric Capital"Liushi, Wenzhou. It was founded in 1997 with a floor area of 4, 003 sq. M, and building area of 5, 600 sq. M. At present, it owns more than 100 staff including 16 engineers.

The Company mainly produces(WENHAN, HX brand) kinds of temperature controller, overheat temperature protectors, temperature displays and gas temperature control valves, which are wideyl applied in electric water heater, electric oven, washing machine, plastic machinery, west cabinet equipment, fuel gas oven, gas air-condition, Turkey cooker, boiler pump, central air-condition heating, ventilation system and such support control products.

The companys is development, production of metallized film capacitors. It is equipped with advanced production equipment and detection instruments. The products are of stable and reliable quality and widely used in fields such as communication, household appliances, power supply, green lighting, commputer, industrial control, electric tool, auto-eletctonics, etc.

Since the foundation of the company, we have always insisted on the principle of paying equal attention to talents and products; Absorbing experienced engineers and professional managing personnel. Basing on strict management, high techonlogy, advanced mechanical facilities, perfect test technique, it can provide the user whit high quality products and good fater-sales service. The main products have been certified to CSA, VED, CQC and CE. The quality control system has been wholly carried out in conformity with ISO. The products mand by our company are used with those of famous domestic manufacturers. The company has become the cooperation partner of foreign famous brand OEM. The products are well sold all over China and also exported abroad, selling well around China and exported oversas.
