Copper Base PCB Board Greeb Solder Mask Solder-Ability Test
| Price: |
US $ 3.5/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-579-V5.79 |
| Aluminum Core: |
1W / Dielectric Material |
| Final Foil External: |
9 Oz |
| Final Height Of PCB: |
1.2mm |
| Surface Finish: |
OSP |
| Solder Mask Color: |
N/a |
| Colour Of Component Legend: |
N/a |
| Via: |
Non Plated Throught Hole (Npth) |
| Mininum Trace (Mil): |
Mininum Trace (Mil) |
| Minimum Gap(Mil): |
14.7 Mil |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Material: |
Aluminum |
| Dielectric: |
Aluminum |
Product Description
Company ProfileBicheng Enterprise Limited is a unique printed circuit board supplier and export enterprise. She
has groups of skilled manufacturing facilities just like the experienced football players in the foot
-ball field and every batch of shipment is like a beautiful gift transmitted to your hands.
Aluminum PCB
High Frequency PCB
Flex PCB
PCB Circuit Board
The components of multilayer PCB: copper foil
A multilayer board consists of copper foils, thin rigid laminates and prepreg sheets.
The standard thicknesses for copper foils are shown below| µm | 5 | 9 | 12 | 17.5 | 35 | 70 |
| oz | 0.14 | 0.25 | 0.34 | 0.5 | 1 | 2 |
Thick copper (heavy copper) foils are used for voltage and ground planes by some electronics
companies. Thicknesses up to 210 µm (6 oz) are specified for high voltage coil boards. For very
fine-line boards, 5 and 9 µm (0.14 and 0.25 oz.), ultrathin copper foils are also used for the outer
layers.
Copper foils are used as copper cladding of the thin laminates used in the inner layers. Such
laminates can be delivered with different copper thicknesses on the two sides, for example,
17.5 µm (0.5 oz.) on one side for a signal layer and 35 µm (1 oz.) on the other side for ground
or voltage planes.
Copper foils are sometimes used directly as cap foils for the outer layers. In such cases, the
copper foils are bonded to the next layers by means of prepreg and form the outer layer circuits.
For signal outer layers, the copper foil thickness is usually 17.5 µm (0.5 oz.) or 35 µm (1 oz.)
depending on the minimum track width and spacing. In the case of high-density fine-line boards,
5 or 9 µm (0.14 or 0.25 oz.) ultrathin copper foils can be the only solution to achieve the required
high resolution when etching the board.
For signal inner layers, a 35 µm (1 oz.) copper foil is normally chosen. For ground and voltage
planes, 35 µm (1 oz.) and 70 µm (2 oz.) copper foils can be used. However, the thicker foil, the
more difficult it is to fill the apertures in the planes around the hole wall with epoxy flowing from
the prepreg sheets during lamination.
Founded in 2003, Bicheng Enterprise Limited is a professional PCB export enterprise. We have established a good relationship of cooperation with well-known enterprises in the same industry.
The factories have been ISO 9001-2008, ISO 14001-2004 and ISO/TS16949-2009 quality management system certified. Over the past 14 years, we have provided professional circuit board manufacturing solutions for more than 5000 companies worldwide.
Different plant scale to suit for your requirements
16000 square meter factory building
30000 square meter month capability
8000 types of PCB per month
ISO9001, ISO14001, TS16949, UL Certified
We have our own advantages to help you saving cost and time spent on PCB, booster your new products go to market quickly.
