Copper Exposure PCB Double Sided board RO4350b with 0.6mm Thickness
| Price: |
US $ 0.45/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Western Union,Paypal |
| Prod Model: |
BIC-114-V1.14 |
| Final Foil External: |
1 Oz |
| Final Height Of PCB: |
0.6mm |
| Surface Finish: |
No Track Finish Required. Copper Exposure. |
| Solder Mask Color: |
No Solder Mask Rerquied. |
| Colour Of Component Legend: |
No Silkscreen Required. |
| Via: |
Plated Through Hole(Pth) |
| Minimum Trace and Space: |
15 Mil/15 Mil |
| Minimum / Maximum Holes: |
0.4/0.4mm |
| Board Plating: |
0.0029" |
| Test: |
100% Electrical Test Prior Shipment |
| Type: |
Rigid Circuit Board |
| Flame Retardant Properties: |
V0 |
| Material: |
Hydrocarbon/Woven Glass |
| Insulation Materials: |
Glass Reinforced Hydrocarbon |
| Dielectric: |
RO4350b 20mil (0.508mm), Tg 288 |
Product Description
High Frequency PCB Circuit Double Sided PCB RO4350B 20mil board Applied In
Multicoupler Combiner
Commodity Introduction
This is a type of RO4350B PCB for the application of Multicoupler Combiner. It's a 2 layer board
at 0.6mm thick.The base laminate is from ROGERS CORP, Solder mask and silkscreen from
Taiyo. It's fabricated per IPC 6012 Class 2 using supplied Gerber data. Each 10 boards or panels
are packed separately.
Parameters & Data Sheet| PCB SIZE | 29 x 87mm=1PCS |
| BOARD TYPE | |
| Number of Layers | Double sided PCB |
| Surface Mount Components | YES |
| Through Hole Components | NO |
| LAYER STACKUP | copper ------- 17um(0.5oz)+plate TOP layer |
| RO4350B 20mil (0.508mm) |
| copper ------- 17um(0.5oz)+plate BOT Layer |
| TECHNOLOGY | |
| Minimum Trace and Space: | 15mil/15mil |
| Minimum / Maximum Holes: | 0.4/0.4mm |
| Number of Different Holes: | 1 |
| Number of Drill Holes: | 1 |
| Number of Milled Slots: | 0 |
| Number of Internal Cutouts: | 0 |
| Impedance Control | no |
| BOARD MATERIAL | |
| Glass Epoxy: | RO4350B 20mil (0.508mm), Tg 288ºC |
| Final foil external: | 1oz |
| Final foil internal: | 0oz |
| Final height of PCB: | 0.6mm ±0.1 |
| PLATING AND COATING | |
| Surface Finish | No track finish required. Copper exposure. |
| Solder Mask Apply To: | No Solder mask rerquied. |
| Solder Mask Color: | No Solder mask rerquied. |
| Solder Mask Type: | No Solder mask rerquied. |
| CONTOUR/CUTTING | Routing |
| MARKING | |
| Side of Component Legend | No silkscreen required. |
| Colour of Component Legend | No silkscreen required. |
| Manufacturer Name or Logo: | No silkscreen required. |
| VIA | Plated through hole(PTH) |
| FLAMIBILITY RATING | UL 94-V0 Approval MIN. |
| DIMENSION TOLERANCE | |
| Outline dimension: | 0.0059" |
| Board plating: | 0.0029" |
| Drill tolerance: | 0.002" |
| TEST | 100% Electrical Test prior shipment |
| APPLICATION: | Multicoupler combiner, 3G Antenna
AC To DC Power Supply
USB Wifi Router
3G USB Modem
Wifi Antennas |
| TYPE OF ARTWORK TO BE SUPPLIED | email file, Gerber RS-274-X, PCBDOC etc |
| SERVICE AREA | Worldwide, Globally. |
