Cu/XLPE (PVC) /Cws/Sta/Lsoh Power Cable & Electric Cable & Cable Wire 3X25 mm2

Cu/XLPE (PVC) /Cws/Sta/Lsoh Power Cable & Electric Cable & Cable Wire 3X25 mm2
Price: US $ 1-5/Meter
Min Order: 500/Meter
Pay Type: L/C,T/T,D/P,Western Union,Paypal
Prod Model: Cu/XLPE/CWS/STA/LSOH power cable 3X25 mm2
Product Name: Cu/XLPE/Cws/Sta/Lsoh Power Cable 3X25 mm2
Usage: Industrial , Construction , Power Station etc
Conductor: Bare Copper
Insulation: PVC
Sheath: PVC
Core Number: 1 2 3 4 5
Core Color: Red Yellow Blue Green or Requirement
Rated Voltage: 0.6/1 Kv
MOQ: 100
Shipping: 3-10 Working Days
Application: Power Station
Voltage: Low and Medium Voltage Cable
Current: DC & AC
Insulation Material: PVC
Certification: VDE
Model: Cu/XLPE/Cws/Sta/Lsoh Power Cable 3X25 mm2
Brand: Chang Qing Teng

Product Description

ITEM NAME : Cu/XLPE/CWS/STA/LSOH power cable 3X25 mm2


1. Introduction

Cross-linked polyethylene insulated power cable not only has excellent electric, mechanical properties, but also has powerful resistance against chemical corrosion, heat aging and environmental stress. Its structure is simple. The long term operating temperature is 90oC. It is convenient to use and can be laid with no restriction of different level.

Our enterprise can produce both flame retardant and non-flame retardant series of XLPE power cable.

Our XLPE power cable can be produced according to your specifications, which are equivalent to IEC, DIN, BS and ASTM, and some indexes are surperior to standards stated above.

The flame-retardant cable coves all kinds of low-smoke lowe-halogen, low-smoke halogen free and three classes of A, B ,C.

We can design and manufacture special XLPE cable according to other standards required by the customers, such as Heavy section cut apart conductors, water-resistance, defend termites, defend mouse and so on.


2. Service conditions and operation parameters of cable

Max. conductor operating temperature90oC
Short circuit temperature250oC
Ambient temperature30oC
Soil temperature20oC
Depth of laying in direct0.8m
Thermal resistance of soil150oC.cm/W
Thermal resistance of ducts120oC.cm/W


3. Application and Main type

TypeDescriptionMain Application
Copper ConductorAluminum Conductor

YJSV23

Cu/XLPE/CWS/STA

L(M.H)PE

N2XSEB2Y

YJLSV23

Al/XLPE/CWS/STA

L(M.H)PE

NA2XSEB2Y

Copper or aluminum conductor XLPE insulated, copperwire+copper tape screen,steel tape armoured, PE/LDPE/HDPE sheathed power cable

For laying indoor, tunnel, underground and canal. Able to bear external mechanical forces, but unable to bear large pulling force. fault current requires large.

CWS(Copper wire screen) tape: Fixed section

WD-YJSY23

Cu/XLPE/CWS/STA/LSOH

WD-YJLSY23

Al/XLPE/CWS/STA/LSOH

Copper or aluminum conductor XLPE insulated, copperwire+copper tape screen,steel tape armoured, LOSH sheathed power cable

YJV32

Cu/XLPE/SWA/PVC

YJLV32

Al/XLPE/SWA/PVC

Copper or aluminum conductor XLPE INSULATED, Copper tape screen, galvanized steel wire armoured, PVC sheathed power cable.For laying in shaft, water under ground and large difference of level, able to bear external mechanical pressure and moderate pulling force.

YJV33

Cu/XLPE/SWA/L(M.H)PE

YJLV33

Al/XLPE/SWA/L(M.H)PE

Copper or aluminum conductor XLPE insulated, copper tape screen, galvanized steel wire armoured, PE/LDPE/HDPE sheathed power cable

WD-YJY33

Cu/XLPE/SWA/LSOH

WD-YJLY33

Al/XLPE/SWA/LSOH

Copper or aluminum conductor XLPE insulated, copper tape screen, galvanized steel wire armoured, LSOH sheathed power cable.

YJSV32

Cu/XLPE/CWS/SWA/PVC

N2XSWRY

YJLSV32

Al/XLPE/CWS/SWA/PVC

NA2XSWRY

 Copper or aluminum conductor XLPE insulated, copper wire+copper tape screen, galvanized steel wire armoured, PVC sheathed power cable

 For laying in shaft, water under ground and large differnce of level, able to bear extenal mechanical pressure and moderate pulling force. fault current requires large.

CWS(Copper wire screen) tape: Fixed secion

 YJSV33

Cu/XLPE/CWS/SWA/L(M.H)PE

N2XSER2Y

YJLSV33

Al/XLPE/CWS/SWA/L(M.H)PE

NA2XSER2Y

Copper or aluminum conductor XLPE insulated, copper wire+copper tape screen, galvanized steel wire armoured, PE/LDPE/HDPE sheathed power cable

 WD-YJY33

Cu/XLPE/SWA/LSOH

WD-YJLY33

Al/XLPE/SWA/LSOH

Copper or aluminum conductor XLPE insulated, copper wire+copper tape screen, galvanized steel wire armoured, LSOH sheathed power cable
