Czl716A Small Weight Sensor 4kg for Kitchen Scales

Name: Czl716A Small Weight Sensor 4kg for Kitchen Scales
Brand: all-electronics-online.com
SKU: 815160795
Availability: InStock
Rating: 4.5 (136 reviews)

Price:	US $ 2-8/Piece
Min Order:	1/Piece
Pay Type:	T/T,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BND-CZL716A
Range:	4kg
Dimension:	30.235.511.2mm
Comprehensive Error:	0.05fs
Rated Output:	3.2±0.3mv/V
Non-Linearity:	0.02%Fs
Hysteresis:	0.02%Fs
Input Resistance:	1090±10Ω
Defend Grade:	IP66
Output Resistance:	1000±10Ω
Excitation Voltage:	5~10VDC

Product Description

CZL716A small weight sensor 4kg for kitchen scales

Model: CZL716A
Category: micro load cell
Range: 4kg
Dimension: 30.2*35.5*11.2mm
Material: alloy steel
Application: handle scale,kitchen scale,fish scale,post scale
Characteristic: micro load cell, miniature load cell,miniature weight sensor

Load Cell,Micro Load Cell,Miniature Load Cell,Small Load

Specification
comprehensive error:	0.05FS	output resistance:	1000±10Ω
Rated output:	3.2±0.3mv/v	Insulation resistance:	≥2000MΩ(100VDC)
Non-linearity:	0.02%FS	Excitation voltage:	5~10VDC
Hysteresis:	0.02%FS	compensated temp:	-10~+40ºC
Repeatability:	0.02%FS	use temperature:	-20~+55ºC
Creep:	0.02%FS/10MIN	temp effect on zero:	0.02%FS/10ºC
Zero balance:	1±0.1%FS	Temp effect on span:	0.02%FS/10ºC
Input resistance:	1090±10Ω	defend grade:	IP66

FAQ
What about your quality?
Each equipment must be carry out 100% examination and test again before shipping

What is the MOQ ?
if we have in store MOQ can be 1 sample
if we dont have in store , the MOQ will be 5 sample

what is the lead time ?
if we have in stock,it will be shipping to you within 3-5days.
if we dont have it in store ,it will need 10-40days.

How long the delivery time ?
Generally most equipment will be 3-10days after we receive your payment or the order conformed ,please conform with us before you made an order .

What is the warranty of the products?
One year ,but we can provide you life long support .

What is the package
Export standard Solid wooden case

What is the shipping way ?
We have stable forwarding agent for air and sea transportation ,and also express about DHL TNT etc , we will suggest you the best shipping way base on your requirement .

What is the payment term ?
T/T, Western Union,Money gram ,Paypal etc

How to contact us ?
