DC Input 18~36V SD-50b-12 DC Power Supply, Small DC-DC, Switching Power Supply

Name: DC Input 18~36V SD-50b-12 DC Power Supply, Small DC-DC, Switching Power Supply
Brand: all-electronics-online.com
SKU: 839926655
Availability: InStock
Rating: 4.4 (40 reviews)

Price:	US $ 17-18/Piece
Min Order:	10/Piece
Pay Type:	L/C,T/T,Western Union,Paypal,Money Gram

Contact Supplier

Showroom Product Company Profile

Prod Model:	SD-50
Output Type:	Single
Warranty:	1 Year
Output Power:	1 - 50W
Connection Mode:	Series Switching Power Supply
Starting Mode:	Separate-excited Switching Power Supply
Voltage Regulating Mode:	Frequency Modulation Type
Power Supplying System:	Terminal Power Distribution Equipment
Certification:	CCC
Input Voltage:	9.2-72VDC
Brand:	Ann

Product Description

DC / DC 50W Switching Power Supply

Features:

1. DC Input A: 9.2~18V / B: 18~36V / C: 36~72V

2. Protections: Short circuit / Overload / Over voltage / Over temperature

3. 100% full load burn-in test

4. Low cost, high reliability

5. 12 months warranty

Specifications:

MODEL	SD-50A-05	SD-50B-05	SD-50C-05	SD-50A-12	SD-50B-12	SD-50C-12	SD-50A-24	SD-50B-24	SD-50C-24
OUTPUT	5V			12V			24V
	10A			4.2A			2.1
	0~10A			0~4.2A			0~2.1A
	50W			50W			50W
	100mVp-p			120mVp-p			150mVp-p
	4.5-5.5VDC			10.5~13.2VDC			21.6~25.4VDC
	±2.0%			±1.0%			±1.0%
	±0.5%			±0.3%			±0.2%
	±0.5%			±0.3%			±0.2%
	2.5s, 50ms ,.....12VDC/24VDC/48VDC at full load
INPUT	A: 9.2~18VDC B: 19~36VDC C:36~72VDC
	70%	73%	76%	72%	75%	78%	74%	80%	83%
	7A/12VDC 3A/24VDC 1.5A/48VDC
PROTECTION	105~160% rated output power
	Protection type :Hiccup mode ,recovers automatically after fault condition is removed
	5.75~6.75V			13.8~16.2V			27.6~32.4V
	Protection type : shut down o/p voltage,re-power on to recover
ENVIRONMENT	~10~+60°C(Refer to output load derating curve)
	20~90%RH non-condensing
	~20~+85°C ,10~95%RH
	±0.03%/°C(0~50°C)
	10~500HZ , 2G 10min./1cycle,60min.each along X,Y,Z axes
SAFETY&EMC(Note4)	I/P~O/P: 2KVAC I/P-FG:1KVAC O/P-FG:0.5KVAC
	I/P~O/P,I/P~FG,O/P~FG:100M Ohms/500VDC/25°C/70% RH
	Compliance to EN55022(CISPR22) CLASS B
	Compliance to EN61000-4-2,3,4,6,8:ENV50204,EN55024,light industry level ,criteria A
OTHERS	1599738mm(LWH)
	0.48kg,24 PCS/12.7kg
