DC Worm Gear Motor for Optical Equipment

Name: DC Worm Gear Motor for Optical Equipment
Brand: all-electronics-online.com
SKU: 774580635
Availability: InStock
Rating: 4.3 (103 reviews)

Price:	US $ 20/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	1/Piece
Pay Type:	T/T,Western Union,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	RS370-WOG
Markets:	North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Application:	Power Tools
Operating Speed:	Constant Speed
Excitation Mode:	Excited
Structure And Working Principle:	Brushless
Certification:	CE,Rosh
Brand:	Longway

Product Description

WIPER MOTOR

Typical Applications:Welding equipment, Intelligent door control, Intelligent office equipment, Automated machinery and equipment.

Motor specification:

Model	Rated Voltage	No Load		Load				Stall
	Rated Voltage	Current	Speed	Current	Speed	Torque	Output Power	Current	Torque
	V	mA	rpm	mA	rpm	g.cm	W	mA	g.cm
RF-370063000	6	≤15	3000	≤100	2200	15	0.33	600	60
RF-370064500	6	≤25	4500	≤270	3300	24	0.8	1200	90
RF-370066000	6	≤40	6000	≤500	4500	30	1.4	1900	120
RF-370123000	12	≤15	3000	≤55	2200	15	0.33	280	60
RF-370126000	12	≤20	6000	≤250	4500	30	1.4	1200	120
RF-370246000	24	≤30	6000	≤130	4500	30	1.4	550	120

Reduction Ratio	276	552,828	649,1656,2484
Max.Gearing Breaking Torque	6kg.cm	15kg.cm	30kg.cm
Max.Gearing Efficiency	73%	65%	59%

Ningbo Yinzhou Longway Technology Co., Ltd. is a professional motor, machinery and electronic products manufacturer in China. Since day one after its establishment, our company has spared no efforts in developing new products and optimizing them. A comprehensive and consistent quality system has been since long established, from design to production, form marketing to after sale service. Our company attaches great importance to employee training. It pays off when the quality of each and every one of our employees keeps improving. Now the motor products include PMDC motors, brushless motors, stepping motors, AC and DC gear motors, synchronous motors, brushless servo motors. Most of products are CE, UL approved. We can also complete OEM/ODM orders in accordance with clients' specific requirements, designs and samples.

The advanced technologies of design and manufacturing were adopted from Germany. We take pride in the CAD/cam mould tooling center and the testing center. We enjoy an excellent reputation in Europe, America, Australia, Middle East, and southeast Asia as well as in China.

"satisfactory products plus satisfactory services" makes our success happen. We sincerely hope to have and also thank for valuable supports and cooperation from all friends in the world.
