Prod Model:	CG0603MLC-05E

Product Description

Lead time	2 to 3 days after receiving the payment.
Remark	100% New and original ; 30 days warranty
Payment	Heng Seng Bank (Hong Kong), Paypal,
Shipment	DHL ,TNT ,FEDEX, UPS or any other express

MANUFACTURER
Bourns

PRODUCT CATEGORY
ESD Suppressors

DESCRIPTION
ESD Suppressor Multilayer Varistor 5V Automotive 2-Pin Case 0603 T/R

Even low voltage discharges can cause damage to electronic components so get this multilayer varistor CG0603MLC-05E ESD protection device from Bourns for added protection. This device's maximum clamping voltage is 20(Typ) V. This ESD diode has a maximum ESD protection device voltage of ±25(Min)@Air Gap/±8(Min)@Contact Disc kV. This ESD diode has an operating temperature range of -40 °C to 85 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. It is made in a single configuration. Its capacitance value is 0.5 pF.

Features
0603 package
Rated for IEC 61000-4-2, level 4 ESD requirements for high speed USB 2.0 or
IEEE1394 applications
Withstands multiple ESD strikes
Low capacitance and leakage currents for invisible load protection
Tape and reel packaging

Specifications
EU RoHS Compliant
Configuration Single
Type Multilayer Varistor
Maximum Working Voltage (V) 5(Typ)
Maximum ESD Protection Voltage (kV) ±25(Min)@Air Gap/±8(Min)@Contact Disc
Maximum Clamping Voltage (V) 20(Typ)
Maximum Leakage Current (uA) 0.05
Capacitance Value (pF) 0.5
Number of Elements per Chip 1
Minimum Operating Temperature (°C) -40
Maximum Operating Temperature (°C) 85
Packaging Tape and Reel
Mounting Surface Mount
Package Height (mm) 0.45
Package Length (mm) 1.6
Package Width (mm) 0.8
PCB changed 2
Standard Package Name Flat Chip
Supplier Package Case 0603
Pin Count 2
Lead Shape No Lead
