Diode Surface Mount Zener Bzx84c12V of Electronic Component

Name: Diode Surface Mount Zener Bzx84c12V of Electronic Component
Brand: all-electronics-online.com
SKU: 796644765
Availability: InStock
Rating: 4.4 (24 reviews)

Price:	US $ 0.027/Piece
Min Order:	1000/Piece
Pay Type:	L/C,T/T,D/P,Paypal

Contact Supplier

Showroom Product Company Profile

Prod Model:	BZX84C12V
Zener Voltage:	12.05 V
Voltage Tolerance:	5 %
Voltage Temperature Coefficient:	8 Mv/K
Zener Current:	5 Ma
Shape:	Sot-23
Encapsulation Structure:	Sot-23

Product Description

Features
• Silicon Planar Power Zener Diodes
• 350mW Power Dissipation
• Standard Zener Voltage Tolerance is ± 5 %
• Ideally Suited for Automated Assembly Processes
• High temperature soldering guaranteed: 260 °C / 10 seconds
in reflow soldering process
• RoHS Compliant

Mechanical Data

Case	SOT-23, Molded Plastic
Terminals	Solderable per MIL-STD-202G, Method 208
Weight	0.0088 grams

Zener voltage: 12.05 V
Voltage tolerance: 5 %
voltage temperature coefficient: 8 mV/K
Zener current: 5 mA
power dissipation: 350 mW
Max reverse leakage current: 100 nA
Max zener impedance: 25 Ohms
Max operating temperature: + 150 °C
Packing type: SMD/SMT
Package: SOT-23
Packing: Reel
Allocation: Single
Min operating temperature: - 55 °C
Series: BZX84C12
Packing pcs: 3000
