Dz47-125 4p 63A 80A 100A 125A MCB

Name: Dz47-125 4p 63A 80A 100A 125A MCB
Brand: all-electronics-online.com
SKU: 722813735
Availability: InStock
Rating: 4.9 (72 reviews)

Price:	US $ 3.2-3.8/Piece
Trade Terms:	FOB,CFR,CIF
Min Order:	200/Piece
Pay Type:	L/C,T/T,D/P

Contact Supplier

Showroom Product Company Profile

Prod Model:	DZ47-125
Markets:	South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Brand Name:	Henuo
Model Number:	Dz47-125
Current:	63 to 125A
Voltage:	230V/440V
Tripping Way:	Distribution and Power
Place Of Origin:	Zhejiang, China
Breaking Capacity:	Low Voltage Circuit Breakers
Operation:	Electric Type
Speed:	Normal Type Circuit Breaker
Arc-extinguishing Medium:	Air
Structure:	MCB
Poles Number:	3
Certification:	CCC

Product Description

Rated Current(In): 20, 32, 63, 80, 100A, 125A
Rated Voltage(Un): 230VAC/400VAC
Number of Poles: 1P, 2P, 3P, 4P
Rated frequency: 50/60Hz
Electrical endurance: 10000 cycles
Mechanical endurance: 20000 cycles
Rated impulse withstand voltage(Uimp): 6kv
Type of Terminal: Lug type
Terminal Capacity: Cable up to 35mm2
Torque of screw: 2.5Nm
IP degree: IP 20
Width: 17.6mm/module
Standards: IEC60947-3, EN60947-31. HL ISOLATOR main switch products
2. CE&CB certificates
3. Plenty OEM experiences
4. New isolating item
Function and Feature:
Capable of switch electric circuit with load
Adaptable to padlock device
Capable of quickly releasing stored energy operation
Highlight of high making and breaking capacity
Used as main switch for household and similar installation

1. Good current limiting feature,Long ARC,High analytical ability,Protect characteristics high precision,Long life and reliable performance.
2.. Obvious contact position state indicator
3..Our company provide all kinds of circuit breaker

Yueqing Heng Nuo Imp. & Exp. Co., Ltd. is the export department for TENGEN GROUP Co., Ltd, it is one leading manufacturer and exporter in the fields of electrical apparatus, wiring accessories, hardware, fire alarm system, tools and so on, our company located in Liushi town of Wenzhou city where is the largest production centre in China for electrical products.

From 1983 to now, our company has cooperated with more than 80 factories, and produces over 20 kinds, thousands of models of high quality electric products yearly. Mainly including:

1. Electrical apparatus: Circuit breaker, AC contactor, Relay, fuse, timer, counter, distribution box, meter socket, current transformer, meter, pushbutton switch, LED pilot lamp, limit switch, pedal switch, float switch, industrial plug & socket, Stabilizer and so on.

2. Wiring accessories: Cable tie, cable clip, cable puller, cable marker, cable lugs, cable glands, terminal blocks, wiring ducts, insulated terminals, MCB insulated busbar, dinrail and so on.

3. Hardware: Flexible conduit & connector, EMT fittings, Metal switch boxes and so on.

4. Tools: Hand crimping tools, cable cutter, hydraulic crimping tool, tester, screwdriver and so on

5. Fire alarm and warning system: Fire alarm bell, electric bell, smoke detector, motor siren, buzzer, warning light and so on

Internationalization standard quality guarantee system:

The product quality of Tengen Group has been strictly controlled in each working procedure,

Many kinds of internationalization standard quality guaranteed system can be highly effective

Under company's strict monitoring. Fellowtrader commended, customer's approval can sufficiently

Make sure of our product quality.

"Tengen" was evaluated as " Chinese famous trademark", Tengen Group has obtained American

FMRC Corporation ISO9001 quality system authentication, ISO14001 environment management

System authentication, CCC authentication, European Union CE safe Authentication, American UL

Authentication and Dutch KEMA authentication and so on, at the same time, it has had the first

Side laboratory -- low voltage electric appliance test center which is the first connected with

International in China.

We promise to offer you superior products, favorable price, and timely delivery. If you are interested in cooperating with us, please feel free to contact with us in your earliest convenience time.
