E2000 APC Singlemode Fixed Type 10dB Fiber Optical Attenuator
| Price: |
US $ 0.68/Piece |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T,D/P,Western Union,Paypal |
| Prod Model: |
E2000 APC Attenuator |
| Model No: |
Tk- E2000 Attenuator |
| Operating Wavelength: |
Sm:1310/1550nm mm: 850 /1300 |
| Return Loss: |
PC>50dB |
| Attenuation Tolerance: |
<1.0 (11-30dB) |
| Storage Temperature: |
-40~85 Degree Centigrade |
| Product Name: |
E2000/APC Fiber Attenuator |
| Customized: |
Available |
| Transmission Medium: |
Single-Mode |
| Structure: |
MU |
| Number Of Cores: |
Single-Core |
| Ferrule Endface: |
APC |
Product Description
E2000 APC Singlemode fixed type 10dB Fiber Optical Attenuator
Fiber optic Attenuator is generated by attenuating fiber and provides a controlled attenuation over a very broadband width.The low return loss and high temperature range ensure excellent performance in the nist demanding applications.Fixed type and variable type also available.Plug-in fixed attenuator are mainly used for adjusting the optical power to a desired level.By using metal-ion doped optical fibers,the plug-in fixed attenuators convert optical power into heat and the power is then attenuated inside the devices.The structures of the plug-in fixed attenuators are simple and the power-proof and performance stability is superior when compared to our competitor's products that utilize a metal membrane.We offermutilple options including SC,LC,ST,FC,and MU connector types and definable attenuator values from 1dB to 30dB.They are available in single mode ad mutil mode.
Our single-mode fixed fiber optic attenuators offer low reflection, high mode stability and a variety of attenuation values.Item Details| Fiber Connector | E2000/APC | Connector Gender | Fixed Female to Female |
| Transfer Mode | Singlemode | Attenuation | 1~25dB |
| Operating Wavelength(nm) | 1260~1620(SM) | Attenuation Accuracy | 1-5dB ±0.5, 6-10dB ±0.7, >10dB ±1.0 |
| Return loss | ≥ 65dB | Max Optical Input Power | 200mW |
| Operating Temp Range | -40~75°C | Polarization Dependent Loss | ≤ 0.2dB |
| Storage Temp Range | -40~80°C | Humidity | 95%RH |
| Fully compatible with E2000 fiber optic connectorsPrecise attenuation valuesIndustry standard attenuation levelsLow PDL and insertion lossPrecision polishing for reduced back reflectionHighly Reliable Physical Contact ConnectorsCompartmentalized case provides safe component storage and simple organizationSmall, durable case for easy portabilityRoHS compliant |
Why choose Takfly ?Service1.Customer's logo: Acceptable2.General inspection on fixing before packing3.Third party inspection: Acceptable Quality ControlAll products must go through five checks before manufacturing process 1.Material incoming inspection before production2.Full check after every individual process finished3.Full check after production half-done4.Full check before packing5.Spots check after production packed before shipping Advantages:1.15 years experience in manufacturing fiber optic products..2.Availability of R & D with more than 10 engineers.3.Available of design and making mold with special molding house.4.High quality, attractive price and fast delivery(2-7days)5.OEM, ODM customer designs are also welcomed6.More than 200 workers7.Excellent service Delivery:1.Packing: Plastic bag& carton, Neutral packing or as your required.2.Sample time: 1-3 days after confirm3.Order lead time: 2-7working days depend on quantity and products.4.Shipping port: Shenzhen China or HK5.Shipping term: EXW or FOB Payment: Acceptable by T/T, West Union, PayPal and L/C according to your requirement Shipping 1.Once confirmed the order, and payment sent after finishing goods. 2.Goods will be sent within 7 days with the fast,reasonable and efficient shipping mode such as DHL, EMS, UPS,FEDEX, TNT, etc.3.Please make sure your postal address is correct. Any lost and mistakes because of wrong address are not supplier's responsibility.4.Please do not bid if you disagree with the shipping and handling charge. Contact1.Our working time:8:30am~5:30pm 2.All the inquiries will be replied within 24hours, So please feel free to send us your inquiry.3.When our trade manager is off line, please feel free to leave a message, and tell us the products you need, our model number, and your E-mail address, we will reply to you within 24 hours too.Any question about this E2000 attenuator,please leave me an inquiry,or contact me directly.
Takfly Communications Co., Ltd. is a Hi-Tech enterprise having its own brand and specializing in R&D, manufacture and sales of fiber optical communications equipments.
The main products of TAKFLY include fiber optic patch cord, connector, adapter, optical coupler, attenuator, optic media converter, optic splice closure, optic terminal box, ODF etc, which are widely used in telecommunications, broadband, broadcast, CATV and network industry. All the products acquired the approval of the Network Access License for Telecommunication Equipment Ministry of Information Industry, PRC, ISO9001, UL and CE standard, which ensure the reliability and make them sold very well not only in the domestic market but also the overseas market.
TAKFLY was establish in 2000, grow up rapidly. Now it has workshop area about 3000 square meters, more than 200 workers, the production capacity of fiber optic connectors is about 600, 000PCS per month. It controls the quality constantly and strictly in order to give the best products to the users. The outstanding features and advantage are the high technology, professional and excellent sales team, efficient and sound management, competitive price, wide and superior channels, as well as high-quality and flexible service.
Many international exhibitions upgraded "TAKFLY" as the well-known brand in the world. To be the super leader of the optical communications scopes in China is the goal of TAKFLY. In the next five years, TAKFLY will keep the strategic pattern of development ---"based in South China, penetrate into whole country, extend over the world". It will bring the fiber optic industry into a brilliant future. TAKFLY--- Your Honest Team, will be always ready for you.
