Eoc Master Modem Gepon/Epon/Gpon
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB,CIF,EXW |
| Min Order: |
50/Piece |
| Pay Type: |
T/T,Western Union |
| Prod Model: |
UVE-504 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Chipset: |
Ar7410,Rtl8198 |
| Physical Rate: |
600 Mbps |
| Modulation Frequency: |
7.5 MHz - 67.5MHz |
| Maximum Connected Terminals: |
128 |
| Encryption Mode: |
128-Bit AES |
| Operating Mode: |
Csma/Ca |
| Ethernet Port: |
2* Ge Uplink Port |
| Reflection Loss: |
> 16 dB |
| Physical Size: |
233 mm * 192 mm * 102 mm |
| Certification: |
RoHS |
| Condition: |
New |
| Type: |
Internet Device |
| Function: |
Receiver Data Signal |
Product Description
UVE-504 As an EoC indoor office equipment based on HOMEPLUG AV, UVE-504 provides one EoC connector, two gigabit Ethernet port,. UVE-503 outputs mixed signals to coaxial cable distribution network and works with CNU, to form a solution scheme for last-one-hundred-meter high-speed Internet access network. This scheme achieves NGB (Next Generation Broadcasting Network) user broadband access and helps to bidirectionally reform cable television network broadband and make full use of existing broadband resources..
Features:* Supports connecting to a maximum of 128 terminals
* Supports long distance transmission and withstands strong interference
* Two 10/100/1000BASE-T ports
* Provides two EoC connectors and four cable ports for uplink and downlink
connection
* Built-in with a high-performance filter module.
* Supports modulation frequency in a range of 7.5 MHz to 65 MHz without
interference with existing CATV transmission signals
* Supports a maximum physical transmission rate of 600 Mbps
* Supports SNMP/WEB/CLI management methods
* Supports management bases on a network management platform
* Supports VLAN (802.1Q),QOS (802.1p) and IGMP protocolsTechnical Specification: | System spec |
|
| Chipset | AR7410,RTL8198 |
| Protocol | IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3u,
IEEE 802.3x,IEEE 1901
HTTP, SNMP, TELNET |
| Physical Rate | 600 Mbps |
| Modulation Frequency | 7.5 MHz - 67.5MHz |
Max. Number of
Connected Terminals | 128 |
| Modulation Mode | OFDM, 4096/1024/256/64/16 QAM, QPSK, BPSK |
| Encryption Mode | 128-bit AES |
| VLAN | 4K |
| Port Rate Restriction | A minimum of 64 kbps |
| QoS | Support VLAN priority
Support CoS packet classification
Support ToS(DSCP)packet classification |
| Operating Mode | CSMA/CA |
| Multicast Supported | Support IGMP managing multicast sessions |
| Management Method | Support SNMP, WEB, and CLI management |
| Port Spec |
|
| Ethernet Port | 2 x GE uplink port |
| Coaxial Cable Port | 4 * F-type female ports (metric or imperial) for inputting CATV signals and outputting mixed signals. |
| PON Port | 1 x optical port for connecting to data network |
| LED | Power indicator
Link: Link status indicator
GE: GE port status indicator |
| RF Spec |
|
| Impedance | 75 Ω |
| Transmitting Power | 0±3 dBm |
| Reflection Loss | > 16 dB |
| Insertion Loss | < 1.2 dB |
| Receiving Sensitivity | -65dBm |
| General |
|
| Max. Power Consumption | ≤10W |
| Power | 220V |
| Operating Temperature | -30ºC-60ºC |
| Storage Temperature | -40ºC-75ºC |
| Humidity | Operating10%-90%, non-condensing ,Storage Humidity 5%-90% |
| Physical Size | L*W*H: 233 mm * 192 mm * 102 mm |
| Weight | 2kgs |
| Green Standard | RoHS |
We are on the show of CCBN Exhibition:
UVINS is a high-tech enterprise and leading manufacturer of CATV & Digital TV products, which specializes in designing, manufacturing and selling Digital Head-end Equipment, Set-top Box, HFC, and EPON products;
UVINS provides overall DIGITAL TV solution and technical services to the network operators all over the world, such as system design, system integration, technical training, and operation consulting^etc; It not only builds up a complete digital TV system for oversea customers, but also focus on value-added services based on customers needs; Its mainly Digital TV product covers: MEPG2/4 encoder, SD/HD H. 264 Encoder, multiplexer, scrambler, demodulator, set-top box^etc;
UVINS also specialize in HFC+EPON solution for oversea customers, it offers full-line CATV transmission products: 1310nm/1550nm Optical Transmitter, Indoor Optical Receiver, Optical Node, 1550nm EDFA, Optical Transmission Platform, RF trunk amplifier, etc;
Based on our advanced technology, excellent services before and after sales, and our good reputation oversea, we already built up a good and long-term cooperated relationship with customers all over the world, our products have been shipped to over 20 countries including Russia, Germany, Finland, Spain, Poland, Vietnam, Thailand, Cambodia, India, Bangladesh. etc;
We will never save our efforts to satisfy customers with our best qualified products and our best services.
